Cutler-Hammer DS300H2 CH3 DS300H2 SFTY SW HUB

Product Description

The Cutler-Hammer DS300H2 is a safety switch hub designed for electrical distribution systems. This model is reliable and essential for effective electrical control. It is suitable for various applications, providing safety for load centers and circuit breaker enclosures.

• Amperage rating of up to 200A
• NEMA 3R enclosure for protection
• Designed for use with MLO and MCB load centers

Product Highlights

This safety switch hub supports installation in rainproof environments and is compatible with several types of circuit protection devices.

Product Information

Standard Information

• Brand: Cutler-Hammer
• MPN: DS300H2

Technical Specifications

• Type: Rainproof conduit/plate type hub
• Size: 3/4 in
• Amperage Rating: Up to 200A
• Enclosure: NEMA 3R
• Height: 2 inches
• Length: 4.25 inches
• Width: 4.25 inches
• Used With: 200A general duty and heavy-duty safety switches
• Special Features: DS hub
• Notes: Designed for MLO and MCB load centers and circuit breakers
