Cutler-Hammer DH364NRK CH3 DH364NRK 200A 600V SFTY SW

Product Description

The Cutler-Hammer DH364NRK is a safety switch designed for reliable electrical management. This heavy-duty fusible safety switch operates at 200 amperes and is rated for six hundred volts. It is suitable for various applications in commercial and institutional buildings.

• Heavy-duty construction for reliable performance
• NEMA 3R enclosure for outdoor applications
• Fusible with neutral for enhanced safety

Product Highlights

This safety switch features a three-pole design with a four-wire configuration, making it ideal for power distribution tasks. Its robust painted galvanized steel enclosure ensures durability in harsh environments.

Product Information

Standard Information

• Manufacturer: Cutler-Hammer
• UPC: 78211320683

Technical Specifications

• Type: Heavy duty fusible safety switch
• Height: 9.5 inches
• Length: 30 inches
• Width: 18 inches
• Weight: 52 pounds
• Amperage Rating: 200A
• Voltage Rating: 600V
• Max Hp Rating: 50, 50/125, 150 hp (1/3PH @480, 600 V)
• Enclosure: NEMA 3R
• Enclosure Material: Painted galvanized steel
• Number of Poles: Three-pole
• Number of Wires: Four-wire
