Cutler & Hammer C306GN3B Freedom NEMA Overload Relay 60-79A Replaces C306GN3

Product Description

The Cutler & Hammer C306GN3B Freedom NEMA overload relay is designed to operate in the range of sixty to seventy-nine amps. This three-pole thermal overload relay is suitable for NEMA Size one and two, as well as IEC Size G to K. The relay can be mounted on a panel or used as a starter replacement. It is important to note that heaters are required for operation, and the relay features load lugs that are integrated into the base, accepting Series B heater packs.

• Requires heaters
• Compatible with panel mounting
• Provides thermal overload protection

Product Highlights

Product Information

Standard Information

• Brand: Cutler & Hammer
• MPN: C306GN3B

Technical Specifications

• Catalog Number: C306GN3B
• UPC: 782113973241
• Dimensions (HxWxD): 4.5 inches x 4.5 inches x 5.25 inches
• Current Rating: 75 Amps
• Amperage Rating: 60-79A
• Voltage: 600V
• Poles: 3
• Frame Size: NEMA Size 1, 2, IEC Size G-K
• Mounting: Panel mount
• Relay Style: Thermal
• Trip Type: Thermal
