Cutler & Hammer C25CNB125T Definite Purpose Contactor 25A

Product Description

The CUTLER & HAMMER C25CNB125T is an Eaton definite purpose contactor designed for HVACR applications and low-cycle duty applications. This compact, single-pole contactor features a 24 Vac, 50/60 Hz coil and an open enclosure with a metal mounting plate. It is rated for 25A inductive full load and 35A resistive load, with binding head screw and quick connect terminals.

• Compact, single-pole design with shunt
• Binding head screw and quick connect terminals
• Open enclosure with metal mounting plate

Product Highlights

Ideal for heating, air conditioning, refrigeration, data processing, and food service applications.

Product Information

Standard Information

• Brand: CUTLER & HAMMER
• Manufacturer Part Number: C25CNB125T
• Country of Origin: US

Technical Specifications

• SKU: C25CNB125T
• Product Name: Eaton definite purpose contactor
• Catalog Number: C25CNB125T
• UPC: 786685116204
• Product Length/Depth: 2.32 in
• Product Height: 3.19 in
• Product Width: 1.97 in
• Compliances: RoHS Compliant
• Certifications: CSA Certified UL Recognized
• Product Type: Definite purpose contactor
• Amperage Rating: 25A
• Number of Poles: 1
• Type: Non-reversing
• Coil: 24 Vac, 50/60 Hz
• Enclosure: Open with metal mounting plate
• Frame size: Compact, single-pole with shunt
• Inductive full load: 25 A
• Model: Contactor
• Resistive load: 35 A
• Terminals: Binding head screw and quick connect terminals (side-by-side)
• Connection: Quick
• Brand: Eaton - Cutler Hammer
• Control Voltage: 24 V
• Current Rating: 25 A
• Horsepower, Motor, Max at 115 V: 2
• Horsepower, Motor, Max at 230 V: 3
• Manufacturer Part Number: C25CNB125T
• Maximum Operating Temperature: 70 °C
• Minimum Operating Temperature: -25 °C
• Mounting Type: DIN Rail Mount
• Series: C25CN Series
• Special Features: With Shunt
• UPC Code: 786685116204
• Voltage: 24 V
• Poles: 1NO
• Termination: Quick Connect, Screw
• Resistive Rating: 30 A
• Approvals: CSA, UR
