Cutler & Hammer BR130 SP-120/240V-30A CB

Product Description

The CUTLER & HAMMER BR130 is an Eaton BR thermal magnetic circuit breaker designed for circuit protection. This single-pole, 30 A device operates at 120/240V and features a 1-inch plug-on mounting type. It offers a 10 kAIC interrupting capacity and is compatible with BR Type Loadcenters, accepting NO.14-4 AWG Cu/Al wire. This breaker provides essential overcurrent protection for residential and commercial applications.

• Thermal magnetic protection for reliable circuit safety
• 1-inch plug-on design for easy installation
• Single-pole operation suitable for 120/240V systems

Product Highlights

Single-pole, 30A thermal magnetic circuit breaker with 10 kAIC interrupting capacity for 120/240V systems.

Product Information

Standard Information

• Brand: CUTLER & HAMMER
• Manufacturer Part Number: BR130
• Country of Origin: Mexico

Technical Specifications

• Brand: CUTLER & HAMMER
• MPN: BR130
• Breaker Type: Thermal Magnetic Circuit Breaker
• Mounting Type: 1-Inch Plug-On
• Amperage: 30 A
• Interrupting Rating: 10 kAIC
• Poles: Single-pole
• Voltage: 120/240V
• Wire Gauge: NO.14-4 AWG Cu/Al
• Loadcenter Compatibility: Type BR Loadcenters
• Manufacturer: Eaton
• Device Type: Circuit Protection Device
• Protection: Thermal Magnetic
• Trip Functions: LI - Long-Time and Instantaneous
• Operating Frequency: 50/60 Hz
• Number of Phases: 1
• Actuator Type: Quick-Make, Quick-Break
• Operating Temperature: 40 deg C
• HACR Rated: Yes
• Standards: UL Listed and CSA Certified
