Crouse-Hinds TP483 Square Cover 4 inches Raised 1-1/4 inches

Product Description

The CROUSE HINDS TP483 square cover is a 4" steel cover with a raised 1-1/4" design and an open configuration with 2-3/4" ears. It has a capacity of 8.5 cubic inches and is suitable for ordinary/non-hazardous locations. This cover is designed for screw mounting and adheres to NEC/CEC standards.

• Constructed from durable steel
• Features a raised design of 1-1/4"
• 8.5 cubic inch capacity

Product Highlights

The CROUSE HINDS TP483 square cover provides a robust and reliable solution for covering square electrical boxes in various applications.

Product Information

Standard Information

• Brand: CROUSE HINDS
• Manufacturer Part Number: TP483

Technical Specifications

• Product Name: Eaton Crouse-Hinds series square cover
• Catalog Number: TP483
• UPC: 786189104837
• Product Length/Depth: 4 in
• Product Height: 1.25 in
• Product Width: 4 in
• Product Weight: 0.37 lb
• Product Type: Square cover
• Area classification: Ordinary/Non-Hazardous Locations
• Standards type: NEC/CEC
• Box size: 4"
• Capacity: 8.5 cubic in
• Material: Steel
• Type: Raised 1-1/4", open with ears 2-3/4"
• Finish Type: Painted
• Installation Type: Screw-In
