Crouse-Hinds E-Z1016-8377 Female Plug 600 VAC/VDC 2 to 2/0 AWG Red

Product Description

The Crouse-Hinds E-Z1016-8377 is a female plug designed for use in power distribution systems. It supports up to three hundred amps of continuous current and can accommodate wire sizes ranging from two to two-aught AWG. This non-vulcanized plug features a double set screw connection and is made of thermoplastic elastomer. With a voltage rating of six hundred volts, this plug is suitable for various applications including motors, generators, and lighting systems.

• Max current rating of three hundred amps
• Compatible wire sizes from two to two-aught AWG
• Constructed from durable thermoplastic elastomer

Product Highlights

This plug is designed for quick disconnects in power systems, meeting industry standards for safety and reliability.

Product Information

Standard Information

• Brand: Crouse-Hinds
• MPN: E-Z1016-8377

Technical Specifications

• Voltage Rating: 600 V
• Max Amperage: 300 A
• Wire Size Range: 2 to 2/0 AWG
• Connection Type: Double Set Screw
• Material: Thermoplastic elastomer
• Environmental Rating: -40 to 105 C
• Diameter: 1.49 inches
• Length: 7.26 inches
