CRANE L151XU*060 Globe Valve 6 in Nominal Flanged End Style 300 lb

Product Description

The CRANE Globe Valve L151XU*060 is designed for operations requiring regular throttling. This valve is suitable for applications where the pressure drop across the valve is around twenty percent of the inlet pressure. Extended throttling could lead to cavitation or high velocities, causing noise, vibration, or potential damage to piping systems.

• Ideal for throttling service
• Flow characteristics allow accurate and repeatable flow control
• Constructed with a cast steel body and handwheel actuator

Product Highlights

This globe valve features a handwheel actuator, making it easy to operate and adjust flow as needed.

Product Information

Standard Information

• Brand: Crane ChemPharma Energy
• Manufacturer: Crane ChemPharma Energy

Technical Specifications

• Actuator Type: Handwheel
• Body Material: Cast Steel
• End Style: Flanged
• Hand Wheel Diameter: 18 inches
• Inlet to Outlet Length: 17-1/2 inches
• Nominal Size: 6 inches
• Pressure Class: 300 lb
• Pressure Rating: 740 psi
• Series: 151
• Softgoods Material: Graphite Packing
• Temperature Rating: -20 to 100 degrees Fahrenheit
• Top to Inlet Center: 25 inches
• Trim Material: 410 Stainless Steel
