Cps Products mbh4z Refrigerant Manifold 1/4 Inch Sae

Product Description

The CPS PRODUCTS mbh4z is a 4-valve anodized aluminum refrigerant manifold designed for HVAC and refrigeration service work. The block body uses triple seal piston valves with 1/4 inch SAE 45-degree fittings for secure, leak-resistant connections. Gauges measure 3.13 inches (80 mm) and are Class 1.0 rated with an internal silicone dampening cup for flutter-free readings under live system pressure. The manifold supports R-134a, R-22, R-404A, and R-410A refrigerants and reads pressure in PSI with temperature scales in degrees F. Three 5-foot premium black and chrome hoses with 1/4 inch SAE fittings are included. Licensed HVAC technicians use this manifold for charging, evacuation, and diagnostic work on residential and light commercial refrigerant systems.

The mbh4z is suited for HVAC service professionals working on a range of common refrigerant systems. The four-valve configuration allows precise control during charging and recovery operations. Compatible refrigerant scales for R-134a, R-22, R-404A, and R-410A make this manifold versatile across residential air conditioning, heat pump, and refrigeration applications. The included 5-foot hoses provide adequate reach in typical equipment room and rooftop service scenarios.

Key Features

• 4-valve anodized aluminum block body for durability and corrosion resistance
• Triple seal piston valves for reliable shutoff and leak-free service
• 3.13 inch (80 mm) Class 1.0 gauges with internal silicone dampening cup for flutter-free operation
• Supports R-134a, R-22, R-404A, and R-410A refrigerant scales
• Includes three 5-foot premium black and chrome hoses with 1/4 inch SAE fittings
• Ships in a custom tin box for organized storage and transport

Compatibility

Designed for use with R-134a, R-22, R-404A, and R-410A refrigerant systems using standard 1/4 inch SAE service ports, typical of residential and light commercial HVAC and refrigeration equipment.

Installation Notes

This manifold is intended for use by EPA 608-certified HVAC technicians. Always recover refrigerant in compliance with applicable EPA regulations before opening a system. Verify that hose fittings are hand-tight and free of damage before pressurizing. Do not exceed the rated pressure range of the gauges during service.

Technical Specifications

• Body Type: 4-valve anodized aluminum block
• Valve Type: Triple seal piston valves
• Gauge Size: 3.13 inches (80 mm)
• Gauge Class: Class 1.0 with internal silicone dampening cup
• Refrigerant Scales: R-134a, R-22, R-404A, R-410A
• Pressure Scale: PSI
• Temperature Scale: degrees F
• Hoses: 3 x 5 feet, black and chrome, 1/4 inch SAE fittings
• Fitting Size: 1/4 inch SAE 45-degree
• Warranty: 1 year
• Packaging: Custom tin box

Standard Information

• Brand: CPS PRODUCTS
• Manufacturer Part Number: mbh4z
