Coxreels TSHL-N-650-BXN Fuel Hose Reel 1 in 50 Ft

Product Description

The COXREELS TSHL-N-650-BXN is a supreme-duty, dual pedestal, box-style frame fuel hose reel built for high-demand fuel dispensing environments. It accepts a 1 inch ID hose with a 1.5 inch OD and accommodates up to 50 feet of hose length. The reel features a machined zinc-plated steel 90-degree full-flow NPT swivel and a cartridge-style motor that is fully enclosed and lubricated for easy field removal. CNC robotically spun and ribbed discs with rolled edges deliver structural strength while protecting hose integrity. Licensed HVAC technicians, fueling equipment installers, and fleet maintenance professionals install this unit on fixed and mobile systems alike.

This reel is designed for non-aromatic fuel applications including diesel, kerosene, fuel oil, and heating oil. Typical deployment locations include fuel storage dispensing systems, fuel and lube service trucks, aircraft refuelers, tank trucks, and ground support utility vehicles. The multi-position guide arm supports wall, floor, ceiling, and vehicle mounting orientations, making this reel adaptable to a wide range of fixed or transport installations. A solid one-piece steel base with dual pedestal support and no-weld construction provides the stability required in mobile and vibration-prone service environments.

Key Features

• 90-degree full-flow NPT swivel machined from zinc-plated steel, rated for fuel dispensing service
• Enclosed, lubricated cartridge-style motor is removable without special tooling for safe maintenance
• Heavy-duty CNC robotically spun and ribbed discs with rolled edges for hose protection and operator safety
• Solid one-piece steel base with dual pedestal design and exclusive triple axle support system — no weld construction
• Multi-position guide arm adjusts for wall, floor, ceiling, and vehicle mounting configurations
• CPC powder coat finish is chip-resistant and rust-inhibiting for long service life in harsh environments
• Permanently lubricated precision bearings for maintenance-reduced operation

Compatibility

Designed for non-aromatic fuel applications including diesel, kerosene, fuel oil, and heating oil; suitable for use on fuel storage dispensing systems, fuel and lube trucks, aircraft refuelers, and tank trucks as part of the COXREELS T Series supreme-duty dual pedestal reel lineup.

Installation Notes

Installation is typically performed by qualified fueling equipment technicians or fleet maintenance professionals. Before servicing or mounting, shut off all fuel supply lines and relieve hose pressure completely. Verify that mounting surface and fastener ratings are adequate for the combined weight of the reel and a full hose load. Consult applicable local codes and NFPA standards governing fuel-handling equipment installation.

Technical Specifications

• Hose ID: 1 inch
• Hose OD: 1.5 inches
• Hose Capacity: 50 feet
• Frame Style: Dual pedestal box-style frame
• Swivel: 90-degree full-flow NPT, zinc-plated steel
• Motor Type: Enclosed cartridge-style, lubricated
• Disc Construction: CNC robotically spun and ribbed with rolled edges
• Finish: CPC powder coat, chip-resistant and rust-inhibiting
• Length: 25 inches
• Width: 13 inches
• Height: 27 inches
• Weight: 77 pounds
• UPC: 674255738522

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: TSHL-N-650-BXN
