Coxreels TSHFL-N-535 Fuel Hose Reel 3/4 in 35 Ft

Product Description

The COXREELS TSHFL-N-535 is a supreme-duty, dual-pedestal fuel hose reel built for continuous-duty fuel dispensing in demanding transport and fleet service environments. Part of the T Series lineup, this reel accepts 3/4 inch ID hose up to 35 feet and is engineered to handle non-aromatic fuels including diesel, kerosene, fuel oil, and heating oil. The frame uses a solid one-piece steel base with a dual-pedestal design and no-weld construction for maximum stability. A CNC robotically spun disc set with rolled edges adds structural strength while protecting hose integrity during repeated uncoiling cycles. Licensed HVAC techs, fueling equipment technicians, and fleet service pros specify this reel for bulk liquid handling systems.

The TSHFL-N-535 is suited for fixed and mobile fuel dispensing installations. Common applications include fuel and lube trucks, aircraft refuelers, tank trucks, bulk fuel storage dispensing systems, and ground support utility vehicles. The multi-position guide arm adjusts for wall, floor, ceiling, and vehicle mounting, making it adaptable to tight equipment bays or open service bays alike. The convenient hose control system enables efficient, controlled fuel transfers in high-cycle operations where operator safety and throughput both matter.

Key Features

• Dual-pedestal T Series frame with solid one-piece steel base and no-weld construction for stability
• CNC robotically spun and ribbed discs with rolled edges for hose protection and operator safety
• Machined solid-brass 90-degree full-flow NPT swivel rated for fuel dispensing service
• Enclosed, lubricated cartridge-style motor is removable for maintenance without full reel disassembly
• Multi-position guide arm mounts to wall, floor, ceiling, or vehicle surfaces
• CPC powder coat finish resists chips, rust, and chemical exposure in outdoor and shop environments
• Permanently lubricated precision bearings with an exclusive triple axle support system

Compatibility

Designed for non-aromatic fuel applications including diesel, kerosene, fuel oil, and heating oil. Intended for use on fuel storage dispensing systems, fuel and lube trucks, aircraft refuelers, tank trucks, and ground support transport equipment. Accepts 3/4 inch ID hose up to 35 feet.

Installation Notes

Installation should be performed by a qualified fueling equipment technician or fleet maintenance professional familiar with applicable fire codes and fuel handling regulations. Shut off all fuel supply lines and depressurize the system before mounting or connecting the reel. The multi-position guide arm must be secured to a structurally sound mounting surface rated for the combined weight of the reel and filled hose. Follow all local fire marshal and NFPA guidelines governing fuel dispensing equipment installation.

Technical Specifications

• Hose ID: 3/4 inch
• Hose Outer Diameter: 1 3/16 inch
• Hose Length Capacity: 35 feet
• Frame Style: Dual Pedestal (T Series)
• Base Material: Steel, one-piece no-weld construction
• Swivel Material: Solid brass, 90-degree full-flow NPT
• Finish: CPC powder coat, chip and rust resistant
• Unit Length: 25 inches
• Unit Width: 13 inches
• Unit Height: 27 inches
• Weight: 67 pounds
• UPC: 674255748088

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: TSHFL-N-535
