Coxreels TSHF-N-535 Fuel Hose Reel 3/4 in 35 Ft

Product Description

The COXREELS TSHF-N-535 is a supreme-duty dual pedestal fuel hose reel engineered for demanding non-aromatic fuel dispensing applications including diesel, kerosene, fuel oil, and heating oil. Built on the T Series frame, it accepts 3/4 inch ID hose and handles up to 35 feet of hose capacity. The reel features a machined solid brass 90-degree full-flow NPT swivel, CNC robotically spun and ribbed discs with rolled edges, and a one-piece steel base with no-weld construction. A licensed HVAC tech, fleet maintenance technician, or fueling equipment installer would typically specify this unit for fixed or mobile fuel dispensing service.

This reel is suited for utility operations, ground support equipment, bulk liquid handling transport, fuel and lube trucks, aircraft refuelers, and tank trucks. Its multi-position guide arm adjusts for wall, floor, ceiling, and vehicle mounting, making it adaptable to a wide range of installation environments. The enclosed cartridge-style motor is removable for maintenance without major disassembly, reducing service downtime in high-cycle dispensing setups.

Key Features

• Supreme-duty dual pedestal T Series frame with one-piece steel base and no-weld construction for maximum stability
• Machined solid brass 90-degree full-flow NPT swivel rated for fuel dispensing service
• CNC robotically spun and ribbed discs with rolled edges for strength, durability, and hose protection
• Lubricated and enclosed cartridge-style motor is easily removable for safe maintenance
• Multi-position guide arm mounts to wall, floor, ceiling, or vehicle
• CPC powder coat finish is chip resistant and rust inhibiting; includes adjustable solid rubber hose stop and permanently lubricated precision bearings

Compatibility

Designed for non-aromatic fuel dispensing applications including diesel, kerosene, fuel oil, and heating oil. Intended for use on fuel storage dispensing systems, fuel and lube trucks, aircraft refuelers, and tank trucks as part of the COXREELS T Series supreme-duty dual pedestal reel platform.

Installation Notes

Installation should be performed by a qualified fueling equipment technician or industrial maintenance professional familiar with fuel system plumbing. Shut off all fuel supply and depressurize the line before mounting or servicing the reel. Follow all applicable local and national codes governing fuel dispensing equipment installation, including proper bonding and grounding requirements for flammable liquid handling. Verify thread compatibility and use appropriate thread sealant rated for fuel service on all NPT connections.

Technical Specifications

• Hose ID: 3/4 inches
• Hose Capacity: 35 feet
• Frame Style: Dual pedestal T Series
• Swivel Material: Solid brass, 90-degree full-flow NPT
• Base Material: One-piece steel, no-weld construction
• Finish: CPC powder coat, chip resistant and rust inhibiting
• Length: 25 inches
• Width: 13 inches
• Height: 27 inches
• Weight: 77 pounds

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: TSHF-N-535
