Coxreels SG17W-150 Welding Gas Hose Reel 50 Ft Spring

Product Description

The COXREELS SG17W-150 is a spring-driven welding gas hose reel designed for oxy-acetylene and T Grade gas welding hose in demanding trade environments. It features an external 90-degree full-flow dual-ported brass swivel with Viton seals, allowing both inlet and outlet connections from the same side of the reel without removing it from its mount. The reel ships with a 1/4-inch ID hose capacity and 50-foot hose length, and its cartridge-style motor is fully enclosed and lubricated for field-serviceable maintenance. Weighing 59 pounds and measuring 17.5 inches long by 8.5 inches wide by 19.25 inches tall, this unit is built for permanent or temporary installation on vertical flat surfaces.

The SG17W-150 is part of the COXREELS SGW Series, engineered specifically for oxy-acetylene and T Grade gas welding hose applications. Typical installations include service vehicles, tool benches, vertical walls and beams, vehicle lift systems, and machine tool stations. The two-bolt side-mount pattern allows quick attachment and detachment from any vertical flat surface, making it a practical choice for shops and mobile service rigs where space is limited. A six-position adjustable guide arm and roller assembly give the installer precise hose routing control in tight or confined spaces.

Key Features

• External 90-degree full-flow dual-ported brass swivel with Viton seals — both connections accessible from the same side, no dismounting required
• Enclosed cartridge-style spring motor is removable for maintenance without disassembling the reel
• Heavy-duty CNC robotically spun and ribbed discs with rolled edges for strength, durability, and operator safety
• Six-position adjustable guide arm and roller assembly for precise hose control in restricted spaces
• Two-bolt side-mount pattern for fast installation or removal on any vertical flat surface
• CPC powder coat finish resists chips, rust, and corrosion for long service life

Compatibility

The SG17W-150 is designed for oxy-acetylene and T Grade gas welding hose and is part of the COXREELS SGW Series of side-mount spring-driven hose reels. Compatible mounting surfaces include vertical flat panels, cabinets, enclosed spaces, service vehicle walls, and beams.

Installation Notes

Installation should be performed by a qualified technician familiar with welding gas systems and applicable safety codes. Shut off all gas supply valves and ensure the hose is fully depressurized before mounting, connecting, or servicing the reel. Secure the unit to a structurally sound vertical surface using the two-bolt mounting pattern and verify all swivel connections are leak-free before returning the system to service. Do not use with hose types or gases outside the manufacturer-specified ratings for this reel series.

Technical Specifications

• Hose ID: 1/4 inch
• Hose Length: 50 feet
• Drive Type: Spring driven
• Swivel Type: External 90-degree dual-ported brass with Viton seals
• Disc Construction: CNC robotically spun and ribbed steel with rolled edges
• Mount Style: Side mount, vertical flat surface, 2-bolt pattern
• Guide Arm Positions: 6 adjustable positions
• Length: 17.5 inches
• Width: 8.5 inches
• Height: 19.25 inches
• Weight: 59 pounds
• Finish: CPC powder coat

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: SG17W-150
