Coxreels P-LP-430-AL Aluminum Spring Driven Hose Reel

Product Description

The COXREELS P-LP-430-AL is an aluminum, spring-driven hose reel built for professional-grade service where corrosion resistance and reduced weight are priorities. Part of the Alumi-Pro Series, this reel is constructed from high-quality aluminum, delivering the structural strength associated with steel at a significantly lower weight. It accepts hose with a 1/2 inch ID and 3/4 inch OD, and accommodates up to 30 feet of hose. The reel weighs 28 pounds and measures 17.5 inches long, 8.5 inches wide, and 19.25 inches tall. Licensed HVAC technicians, plumbers, and general service contractors install this type of reel in mobile service units, shops, and fixed service bays.

The P-LP-430-AL is suited for light-to-medium duty fluid or air delivery applications where a steel reel would add unwanted weight or where corrosion from moisture or chemicals is a concern. Its multi-position guide arm supports wall, floor, ceiling, and vehicle mounting, making it adaptable to a range of service environments. The single-pedestal aluminum base provides stable support without welded joints, keeping the overall assembly rigid and maintenance-friendly.

Key Features

• High-quality aluminum construction — corrosion resistant and lighter than comparable steel reels
• Machined solid brass 90-degree full-flow NPT swivel for simplified seal maintenance without removing the reel from its mount
• Enclosed, lubricated cartridge-style spring motor is removable for convenient service; precision coil spring is factory tuned to the application
• Heavy-duty CNC robotically spun and ribbed discs with rolled edges for added strength, hose protection, and operator safety
• Multi-position aluminum guide arm adjusts for wall, floor, ceiling, and vehicle mounting configurations
• CPC powder coat finish — chip resistant and rust inhibiting; includes adjustable solid rubber hose stop and permanently lubricated precision bearings

Compatibility

Designed as a spring-driven hose reel for use with 1/2 inch ID hose up to 30 feet in length; the Alumi-Pro Series is modeled after the Coxreels P Series and serves as an aluminum alternative where polypropylene or plastic reels are insufficient in strength or durability.

Installation Notes

Installation should be performed by a qualified service technician familiar with hose reel mounting requirements. Depressurize and disconnect the hose from any fluid or air supply before mounting or servicing the reel. Ensure the mounting surface is rated for the combined weight of the reel and fully loaded hose. Consult local codes for vehicle or overhead mounting applications.

Technical Specifications

• Hose ID: 1/2 inch
• Hose OD: 3/4 inch
• Hose Length Capacity: 30 feet
• Drive Type: Spring driven
• Material: Aluminum
• Length: 17.5 inches
• Width: 8.5 inches
• Height: 19.25 inches
• Weight: 28 pounds
• UPC: 674255730496

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: P-LP-430-AL
