Coxreels P-LP-425-AL Aluminum Spring Driven Hose Reel

Product Description

The COXREELS P-LP-425-AL is a spring-driven, professional-grade aluminum hose reel designed for trade and industrial applications where weight savings and corrosion resistance matter. Built on the proven P Series platform, this reel uses high-quality aluminum construction throughout, giving it the structural strength of comparable steel reels at a significantly reduced weight. Key specs include a 1/2 inch inner diameter hose path, 3/4 inch outer diameter, and a 25-foot hose capacity. The spring-return motor is factory-tuned and enclosed in a cartridge housing for reliable retraction and straightforward field maintenance. Licensed plumbers, HVAC technicians, and fleet service professionals are the primary installers of this type of reel.

The P-LP-425-AL suits residential and light commercial service environments where a durable, non-corrosive reel is required. Its multi-position aluminum guide arm accommodates wall, floor, ceiling, and vehicle mounting, making it well suited for service vans, shop bays, and mechanical rooms. The powder coat finish resists chipping and rust, which extends service life in humid or outdoor-adjacent environments. Because aluminum is used in place of polypropylene or plastic, this reel handles applications that demand higher load ratings and longer cycle life than standard polymer reels can support.

Key Features

• High-quality aluminum construction: corrosion-resistant and lighter than steel equivalents
• Enclosed cartridge-style spring motor: lubricated, removable, and factory-tuned for the rated hose length
• Machined solid brass 90-degree full-flow NPT swivel: supports simple seal maintenance without removing the reel from its mount
• Heavy-duty CNC robotically spun and ribbed discs with rolled edges for hose protection and operator safety
• Solid one-piece aluminum base and support post, no-weld single pedestal design for maximum stability
• Multi-position aluminum guide arm adjusts for wall, floor, ceiling, and vehicle mounting
• CPC powder coat finish: chip-resistant and rust-inhibiting for long service life

Compatibility

Designed as a direct-fit, OEM-style spring-driven hose reel for service applications requiring a 1/2 inch ID, 25-foot capacity aluminum reel in the P Series form factor.

Installation Notes

Installation should be performed by a qualified technician familiar with hose reel mounting and fluid system connections. Shut off the supply line and depressurize the hose before mounting or servicing the reel. Verify that the mounting surface and hardware are rated for the combined weight of the reel and a fully loaded hose. Follow applicable facility or vehicle codes when routing hose and securing the inlet connection.

Technical Specifications

• Hose Inner Diameter: 1/2 inch
• Hose Outer Diameter: 3/4 inch
• Hose Capacity: 25 feet
• Drive Type: Spring driven
• Material: Aluminum
• Swivel Material: Solid brass
• Finish: CPC powder coat
• Length: 17.5 inches
• Width: 8.5 inches
• Height: 19.25 inches
• Weight: 29 pounds
• UPC: 674255729070

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: P-LP-425-AL
