Coxreels P-LP-125-AL Aluminum Spring Driven Hose Reel

Product Description

The COXREELS P-LP-125-AL is an aluminum spring-driven hose reel from the Alumi-Pro Series, designed for professional-grade fluid and air delivery in demanding service environments. Built from high-quality aluminum, it delivers the structural strength typically associated with steel reels while cutting down on overall weight and eliminating corrosion concerns. The spring motor is factory-tuned and enclosed in a cartridge housing for long service life. With a 1/4 inch inner diameter and 25 foot hose capacity, this reel suits light-to-medium duty applications where durability and compact form factor are both priorities. Licensed tradespeople and fleet service technicians are the primary installers.

The P-LP-125-AL is suited for use in automotive service shops, industrial maintenance settings, fleet and vehicle-mounted installations, and commercial facilities where a lightweight, non-corrosive reel is preferred over polypropylene or plastic options. Its multi-position guide arm adjusts to accommodate wall, floor, ceiling, and vehicle mounting configurations, making it versatile across a range of service environments. The single-pedestal aluminum base provides a stable footprint without welded joints.

Key Features

• High-quality aluminum construction reduces weight compared to steel while maintaining professional-grade strength and corrosion resistance
• Enclosed cartridge-style spring motor is lubricated, removable, and factory-tuned for extended service life
• Machined solid brass 90-degree full-flow NPT swivel allows hose installation and seal maintenance without removing the reel from its mount
• Heavy-duty CNC robotically spun and ribbed discs with rolled edges for added durability and operator safety
• Multi-position guide arm supports wall, floor, ceiling, and vehicle mounting orientations
• CPC powder coat finish is chip resistant and rust inhibiting; includes adjustable solid rubber hose stop and permanently lubricated precision bearings

Compatibility

Designed as an OEM-style aluminum replacement option within the Alumi-Pro Series, modeled after the COXREELS P Series hose reel line, and intended for applications where polypropylene or plastic reels are insufficient due to strength or durability requirements.

Installation Notes

Installation is typically performed by qualified mechanical or maintenance technicians. Before mounting or servicing, depressurize and disconnect the hose line completely. Mounting hardware selection should suit the mounting surface type and comply with applicable workplace safety and facility codes. Do not exceed the rated hose capacity or inner diameter specification for this reel.

Technical Specifications

• Hose Inner Diameter: 1/4 inch
• Hose Outer Diameter: 1/2 inch
• Hose Length Capacity: 25 feet
• Drive Type: Spring driven
• Swivel Type: Machined solid brass 90-degree full-flow NPT
• Length: 14.5 inches
• Width: 6.75 inches
• Height: 16 inches
• Weight: 18 pounds
• Material: Aluminum (frame, discs, base); Brass (swivel)
• Finish: CPC powder coat, chip resistant and rust inhibiting
• Sold As: Each

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: P-LP-125-AL
