Coxreels EZ-TBLL-3100 Pure Flow Hose Reel 3/8 in 100 Ft

Product Description

The COXREELS EZ-TBLL-3100 is a motorized Pure Flow series hose reel designed for safe, contamination-free transfer of breathing air, potable water, and other clean fluids in demanding trade environments. It features a full stainless steel air and fluid path along with a stainless steel swivel packed with non-toxic, food-grade grease, making it suitable for respiratory air systems and drinking water applications. The reel accommodates a 3/8 inch ID, 5/8 inch OD hose up to 100 feet in length. Licensed HVAC techs, plumbers, and industrial service professionals specify this reel where sanitary fluid transfer and reliable hose management are required.

The EZ-TBLL-3100 is built for both residential and commercial installations where clean fluid delivery lines must be stored safely and retrieved quickly. Typical applications include low and high pressure breathing air systems, potable water distribution lines, and any hose service requiring sanitized, non-contaminated fluid transfer. The motorized retraction drive is housed in a self-contained cartridge-style motor assembly that can be removed independently for maintenance without disturbing the reel mounting. The reel ships as a single unit and mounts on a solid one-piece steel dual pedestal base measuring 25 inches long, 13 inches wide, and 27 inches tall.

Key Features

• Full stainless steel air and fluid path with machined 90-degree full-flow NPT swivel inlet for corrosion-free, non-contaminated transfer
• Non-toxic food-grade grease in stainless steel swivel — approved for potable water and breathing air service
• Enclosed cartridge-style motorized retraction drive is removable for safe, convenient maintenance without full reel disassembly
• Heavy-duty CNC robotically spun and ribbed discs with rolled edges for added strength, hose protection, and operator safety
• Solid one-piece steel dual pedestal base with no-weld construction and Coxreels triple axle super hub support for maximum stability
• CPC powder coat finish is chip-resistant and rust-inhibiting; includes adjustable guide arm and permanently lubricated precision bearings

Compatibility

Designed as an OEM-style replacement and direct-fit Pure Flow series motorized hose reel for applications requiring sanitized fluid transfer with 3/8 inch ID hose up to 100 feet.

Installation Notes

Installation should be performed by a qualified plumber, industrial mechanic, or compressed air system technician familiar with applicable plumbing and safety codes. Shut off the fluid or air supply and depressurize the line completely before connecting or disconnecting the hose reel. Secure the base to a stable mounting surface using hardware appropriate for the substrate and load. Verify NPT thread engagement and check for leaks at the swivel inlet before returning the system to service.

Technical Specifications

• Hose ID: 3/8 inches
• Hose OD: 5/8 inches
• Hose Length: 100 feet
• Retraction Type: Motorized
• Swivel Material: Stainless steel
• Fluid Path Material: Stainless steel
• Base Material: Steel
• Finish: CPC powder coat, chip-resistant and rust-inhibiting
• Unit Length: 25 inches
• Unit Width: 13 inches
• Unit Height: 27 inches
• Weight: 85 pounds
• UPC: 674255724914

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: EZ-TBLL-3100
