Coxreels EZ-P-LP-150 Spring Driven Hose Reel 50 Ft

Product Description

The COXREELS EZ-P-LP-150 is a spring-driven retractable hose reel built for demanding trade applications where reliable hose management is critical. Designed around the proven P Series platform, it accepts a 1/4 inch ID hose up to 50 feet in length and retracts automatically using a lubricated, enclosed cartridge-style motor. The EZ-COIL system slows retraction speed up to 80 percent compared to conventional spring reels, reducing snap-back risk for the operator. CNC robotically spun and ribbed steel discs with rolled edges provide structural integrity and protect hose from abrasion. Licensed HVAC techs, plumbers, and service technicians working out of vans or fixed service bays will find the compact footprint and multi-position guide arm practical for tight installations.

The EZ-P-LP-150 is suited for low-pressure fluid or air line service in residential and light commercial settings. The single-pedestal steel base mounts to walls, floors, ceilings, or vehicle surfaces, making it a common choice for mobile service rigs and shop installations alike. The 90-degree full-flow brass NPT swivel allows hose connection and seal maintenance without removing the reel from its mount, keeping downtime short during field service.

Key Features

• EZ-COIL spring motor retracts up to 80 percent slower than conventional reels for improved operator safety
• Lubricated, enclosed cartridge-style motor is removable for maintenance without full reel disassembly
• Machined solid brass 90-degree full-flow NPT swivel for easy hose installation and seal service
• CNC robotically spun and ribbed steel discs with rolled edges for strength and hose protection
• Solid one-piece steel base and support post, no-weld construction, for maximum stability
• CPC powder coat finish resists chips and rust; adjustable solid rubber hose stop included

Compatibility

Designed as an OEM-style replacement or direct-fit hose reel for low-pressure service applications requiring a 1/4 inch ID, 50-foot hose capacity on a spring-driven retractable reel.

Installation Notes

Installation should be performed by a qualified technician familiar with hose reel mounting requirements for the intended surface type. Shut off and depressurize the fluid or air supply line completely before connecting or disconnecting hose fittings. The multi-position guide arm should be set to the correct mounting orientation before final fastening. Verify that all NPT swivel connections are properly sealed and leak-tested before returning the line to service.

Technical Specifications

• Hose ID: 1/4 inch
• Hose Length Capacity: 50 feet
• Drive Type: Spring driven
• Swivel Material: Solid brass, 90-degree full-flow NPT
• Disc Construction: CNC robotically spun ribbed steel with rolled edges
• Base Construction: One-piece steel, no-weld single pedestal
• Finish: CPC powder coat, chip and rust resistant
• Length: 17.5 inches
• Width: 8.5 inches
• Height: 19.25 inches
• Weight: 40 pounds
• UPC: 674255728981

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: EZ-P-LP-150
