Coxreels ENH-N-325 Enclosed Spring Driven Hose Reel

Product Description

The COXREELS ENH-N-325 is an enclosed, spring-driven hose reel from the EN Series, designed for trade and industrial environments where hose protection and a clean installation appearance are required. The reel is housed in a heavy-gauge, three-piece powder-coated steel casing that shields internal components from dirt, moisture, and physical damage. It accepts 3/8 inch ID hose up to 25 feet in length. A machined zinc-plated steel 90-degree full-flow NPT swivel allows seal maintenance without removing the reel from its mount. The unit weighs 61 pounds and measures 20.5 inches long, 10.5 inches wide, and 22 inches tall. Licensed HVAC, plumbing, and industrial maintenance technicians are the primary installers.

The ENH-N-325 is suited for workshops, service bays, and commercial facilities where a tidy, professional appearance is expected alongside reliable hose retraction. The enclosed casing keeps the reel and hose protected in environments with airborne debris, chemical exposure, or heavy foot traffic. The spring-driven retraction mechanism and multi-position lock ratchet allow controlled hose deployment and positive lockout at any extension length. The adjustable hose roller guide helps prevent kinking at the reel exit point, extending hose service life in high-cycle applications.

Key Features

• Three-piece powder-coated steel enclosure shields reel, hose, and internal components from the elements
• Machined zinc-plated steel 90-degree full-flow NPT swivel allows seal service without dismounting the reel
• Removable cartridge-style spring motor is lubricated and enclosed for safe, convenient maintenance access
• CNC robotically spun and ribbed discs with rolled edges provide strength, durability, and hose protection
• Solid one-piece steel base with single pedestal and no-weld support post for maximum stability
• Multi-position lock ratchet, adjustable solid rubber hose stop, and precision lubricated bearings included

Compatibility

Designed as an OEM-style spring-driven enclosed hose reel compatible with standard 3/8 inch ID hose up to 25 feet in length with NPT swivel connections.

Installation Notes

Installation is typically performed by licensed plumbers, HVAC technicians, or industrial maintenance professionals. Power down or depressurize the supply line before connecting or servicing the reel. Mount to a structurally adequate wall, ceiling, or floor surface capable of supporting the loaded weight of the reel and hose. Verify that swivel and hose end fittings are properly sealed and pressure-tested before returning the system to service.

Technical Specifications

• Hose ID: 3/8 inch
• Hose OD: 11/16 inch
• Hose Capacity: 25 feet
• Drive Type: Spring driven
• Casing Material: Steel
• Finish: CPC powder coat
• Length: 20.5 inches
• Width: 10.5 inches
• Height: 22 inches
• Weight: 61 pounds

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: ENH-N-325
