Coxreels DMPL-375 Dual Product Hose Reel 3/8 in 75 Ft Steel

Product Description

The COXREELS DMPL-375 is a spring-driven dual product hose reel from the DP Series, designed for simultaneous delivery of two fluid lines through a single reel assembly. It features two swivel inlets and two outlets, making it suited for applications requiring separate fluid paths with large-volume, low-to-medium pressure delivery. The box-style steel frame includes heavy-duty cross supports at all four corners for structural rigidity. At 128 pounds, this is a heavy-duty unit built for permanent or semi-permanent installation in demanding service environments. Licensed contractors and shop technicians working with dual-fluid dispensing systems are the primary installers.

The DMPL-375 is intended for commercial and industrial settings where two separate fluid products must be routed and retrieved through a single reel. Typical applications include lubrication systems, fluid dispensing bays, and multi-line service equipment installations. The spring-driven retraction mechanism keeps hose under controlled tension during retrieval. The 3/8 inch inner diameter hose capacity and 75 foot length accommodate a wide range of service bay layouts. Its box-style frame design handles the load of dual large-diameter hoses without flexing under repeated use.

Key Features

• Two external fluid paths with machined solid brass 90-degree full-flow NPT swivel inlets for simple seal maintenance without removing the reel from its mount
• Lubricated and enclosed cartridge-style motor is removable for safe and convenient maintenance
• Heavy-duty CNC robotically spun and ribbed discs with rolled edges for strength, durability, and operator safety
• Reinforced steel box-style frame with two inlets and two outlets handles dual hose applications
• Exclusive low-profile outlet riser and open drum slot design provides a non-crimping, flat smooth hose wrap
• CPC powder coat finish resists chips and rust; stainless steel pinch-proof rollers, stainless steel pawl spring, and self-lubricated flange bearings

Compatibility

Designed as an OEM-style dual product spring-driven hose reel for commercial and industrial fluid delivery systems requiring simultaneous two-line hose management.

Installation Notes

Installation of this hose reel should be performed by a qualified technician familiar with fluid delivery systems and applicable plumbing or industrial equipment codes. Shut off all fluid supply lines and depressurize the system fully before connecting or disconnecting hose or swivel fittings. Mount the reel to a structurally adequate surface using fasteners rated for the combined weight of the reel and fully extended hose. Verify all NPT swivel connections are leak-free before returning the system to service.

Technical Specifications

• Hose Inner Diameter: 3/8 inches
• Hose Outer Diameter: 13/16 inches
• Hose Length: 75 feet
• Frame Material: Steel
• Drive Type: Spring driven
• Inlet/Outlet Configuration: Two swivel inlets, two outlets
• Length: 25.5 inches
• Width: 22 inches
• Height: 22 inches
• Weight: 128 pounds
• UPC: 674255814318

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: DMPL-375
