Coxreels DLPL-375 Dual Product Hose Reel 75 Ft Spring

Product Description

The COXREELS DLPL-375 is a spring-driven dual product hose reel designed for applications requiring simultaneous delivery through two separate hose lines. Part of the COXREELS DP Series, this reel features two swivel inlets and two outlets, making it well suited for high-volume fluid delivery in low to medium pressure systems. The hose capacity is 75 feet at 3/8 inch ID and 3/4 inch OD. The unit weighs 115 pounds and measures 25.5 inches long by 22 inches wide by 22 inches tall. Licensed HVAC, plumbing, and industrial service technicians working in commercial and large residential environments will encounter this reel in demanding dual-fluid service setups.

The DLPL-375 is built for dual hose service applications where two fluid products must be delivered simultaneously from a single mounted reel. The box-style steel frame with heavy-duty cross supports to all four corners makes it suitable for fixed installations in service vehicles, shop environments, or stationary equipment bays. The spring-driven retraction and dual-swivel inlet design simplify hose deployment and retrieval in high-cycle work environments. This reel is appropriate for low to medium pressure delivery of oils, lubricants, or other compatible fluids requiring dual-line routing.

Key Features

• Two external fluid paths with machined solid brass 90-degree full-flow NPT swivel inlets for simple seal maintenance without removing the reel from its mount
• Enclosed cartridge-style motor is lubricated and easily removable for safe maintenance access
• Heavy-duty CNC robotically spun and ribbed discs with rolled edges for strength, hose protection, and operator safety
• Reinforced steel box-style frame with two inlets and two outlets handles dual hose configurations
• Exclusive low-profile outlet riser and open drum slot design provides a non-crimping, flat smooth hose wrap
• CPC powder coat finish is chip resistant and rust inhibiting; stainless steel pinch-proof rollers and pawl spring; self-lubricated flange bearings

Compatibility

Designed as an OEM-style spring-driven dual product hose reel replacement or new installation unit suitable for fixed-mount dual-hose delivery systems operating at low to medium pressures.

Installation Notes

Installation should be performed by a qualified technician familiar with fluid delivery systems and mounting hardware requirements. Shut off all fluid supply lines and relieve system pressure before removing or installing the reel. Secure the unit to a structurally sound mount capable of supporting the loaded weight of the reel and hose. Follow all applicable local codes and manufacturer torque guidelines for swivel inlet fittings during hose connection.

Technical Specifications

• Hose ID: 3/8 inch
• Hose OD: 3/4 inch
• Hose Length: 75 feet
• Drive Type: Spring driven
• Inlets: 2 swivel NPT brass inlets
• Outlets: 2
• Frame Material: Steel
• Finish: CPC powder coat
• Length: 25.5 inches
• Width: 22 inches
• Height: 22 inches
• Weight: 115 pounds
• UPC: 674255814202

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: DLPL-375
