Coxreels 1275HPL-C-12-A Dual Hydraulic Hose Reel

Product Description

The COXREELS 1275HPL-C-12-A is a heavy-duty dual hydraulic hose reel engineered for high-pressure hydraulic applications up to 10,000 psi. It accommodates hose up to 200 feet in length and is equipped with a hand crank drive mechanism for controlled pay-out and retrieval. The reel is built around a one-piece CNC robotically welded 12-gauge steel A-frame base and features CNC spun, ribbed discs with rolled edges for structural integrity and hose protection. Permanently lubricated, self-aligning pillow block bearings support smooth rotation under load. This unit is suited for demanding field and shop environments where dual hydraulic circuits must be serviced reliably.

The 1275HPL-C-12-A fits dual hydraulic service applications including emergency rescue systems and high-pressure hydraulic tool operations. Its hand crank configuration and 10,000 psi rating make it a practical choice for mobile service vehicles, hydraulic rescue tool stations, and industrial maintenance facilities. Two 1/4-inch BSP female outlet risers with an open drum slot design allow a flat, non-crimping hose wrap, which is important when routing hose repeatedly under pressure. Licensed HVAC, industrial, and hydraulic service technicians install this type of reel as part of fixed or mobile hydraulic equipment setups.

Key Features

• Dual hydraulic configuration with two high-pressure 90-degree full-flow melanized steel 1/4-inch swivels rated for emergency rescue and high-pressure hydraulic tool systems
• Hand crank drive supports hose lengths to 200 feet at working pressures to 10,000 psi
• One-piece CNC robotically welded 12-gauge steel A-frame base with integrated mounting pattern for easy installation and detachment
• CNC robotically spun and ribbed discs with rolled edges for enhanced strength, durability, and operator safety
• Two 1/4-inch BSP female outlet risers with open drum slot design for non-crimping, flat smooth hose wrap
• CPC powder coat finish for chip resistance and rust inhibition; permanently lubricated self-aligning pillow block bearings

Compatibility

The 1275HPL-C-12-A is part of the COXREELS 1275HP Series of dual hydraulic hose reels. It is designed for dual hydraulic circuit applications including emergency rescue systems and high-pressure hydraulic tools requiring a hand crank reel rated to 10,000 psi.

Installation Notes

Installation is typically performed by qualified hydraulic or industrial service technicians. Before mounting, depressurize and isolate all hydraulic lines connected to the system. The steel A-frame base includes a pre-drilled mounting pattern — ensure the mounting surface is rated to support the reel weight and the dynamic loads imposed during hose retrieval under pressure. Follow applicable OSHA and equipment manufacturer guidelines for hydraulic hose assembly and connection torque when attaching fittings to the 1/4-inch BSP female outlets.

Technical Specifications

• Maximum Working Pressure: 10,000 psi
• Hose Capacity: 200 feet
• Hose ID: 0.25 inches
• Hose OD: 0.5 inches
• Drive Type: Hand Crank
• Outlet Connection: 1/4-inch BSP Female (x2)
• Frame Material: 12-Gauge Steel, CNC Robotically Welded
• Finish: CPC Powder Coat
• Weight: 52 pounds
• Length: 25.5 inches
• Width: 18 inches
• Height: 20 inches
• UPC: 674255831513

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1275HPL-C-12-A
