Coxreels 1275-6-75-A Dual Hose Reel 75 Ft Hand Crank Motorized

Product Description

The COXREELS 1275-6-75-A is a large-capacity dual hose reel from the 1275 Series, built for demanding industrial and commercial applications where two hose lines must be managed from a single reel. It accepts hoses with a 1 inch ID and 1 7/16 inch OD, with a 75-foot hose length capacity per line. The reel operates via hand crank or motorized drive and features dual plumbing with two swivel inlets and two low-profile outlets. A one-piece all-welded steel A-frame provides rigid, durable support. Licensed plumbers, pipefitters, industrial maintenance technicians, and fleet service professionals are the typical installers of this unit.

The 1275-6-75-A is suited for large-capacity fluid transfer tasks in industrial facilities, commercial vehicle service bays, agricultural operations, and heavy-duty wash-down stations. The dual-hose configuration allows simultaneous delivery of two separate media or circuits, reducing the need for multiple standalone reels. The open drum slot and low-profile outlet riser design promote a flat, non-crimping hose wrap, keeping hose life maximized even under frequent use. Both hand crank and motorized operation options make this reel adaptable to fixed or semi-portable installations.

Key Features

• Dual plumbing with two machined solid brass 90-degree full-flow NPT swivel inlets for simple seal maintenance without removing the reel from its mount
• Two exclusive low-profile outlet risers with open drum slot design for a flat, non-crimping hose wrap
• One-piece all CNC robotically welded 12-gauge steel A-frame base for superior structural rigidity over bolted designs
• Heavy-duty CNC robotically spun and ribbed discs with rolled edges for hose protection and operator safety
• Permanently lubricated self-aligning pillow block bearings for smooth rotation and long service life
• CPC powder coat finish — chip-resistant and rust-inhibiting for extended service in harsh environments

Compatibility

Designed for large-capacity dual hose reel applications accommodating hoses with a 1 inch ID and 1 7/16 inch OD up to 75 feet in length. Compatible with hand crank or motorized drive configurations as specified in the 1275 Series.

Installation Notes

Installation is typically performed by licensed plumbers, pipefitters, or qualified industrial maintenance technicians. Shut off all fluid supply lines and depressurize the system completely before mounting or connecting hoses. Secure the reel to a structurally sound surface using the mounting pattern built into the steel base. Follow applicable OSHA and facility safety standards when working with pressurized fluid systems.

Technical Specifications

• Hose ID: 1 inch
• Hose OD: 1 7/16 inches
• Hose Capacity: 75 feet per line
• Drive Type: Hand crank or motorized
• Frame Material: 12-gauge steel, all-welded A-frame
• Swivel Material: Solid brass, 90-degree full-flow NPT
• Finish: CPC powder coat, chip-resistant and rust-inhibiting
• Length: 31 inches
• Width: 24 inches
• Height: 27 inches
• Weight: 73 pounds
• UPC: 674255839199

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1275-6-75-A
