Coxreels 1275-6-50-A Dual Hose Reel 1 Inch Id 50 Ft

Product Description

The COXREELS 1275-6-50-A is a heavy-duty dual hose reel from the 1275 Series, built for large-capacity industrial and commercial hose management applications. It accommodates hose with a 1-inch inner diameter and handles up to 50 feet of hose length. The reel ships ready for hand crank or motorized operation and features dual plumbing with two swivel inlets and two low-profile outlet risers. An open drum slot design promotes a flat, non-crimping hose wrap. The one-piece all-welded steel A-frame construction provides rigid, durable support in demanding service environments.

This reel is suited for industrial facilities, fleet service bays, manufacturing floors, and other high-demand settings where large-volume fluid or air delivery is required. The dual hose configuration makes it appropriate for applications that require simultaneous or paired hose circuits. It is typically installed by industrial mechanics or service technicians who need a permanent, wall- or floor-mounted hose management solution. The open drum slot and low-profile riser design support consistent hose layering across the full 50-foot capacity.

Key Features

• Dual plumbing with two machined solid brass 90-degree full-flow NPT swivels for simple seal maintenance and hose installation without removing the reel from its mount
• Two low-profile outlet risers with open drum slot design for a flat, non-crimping hose wrap
• One-piece all-welded 12-gauge steel A-frame base for superior structural rigidity — no bolted joints
• Heavy-duty CNC robotically spun and ribbed discs with rolled edges for strength, durability, hose protection, and operator safety
• Permanently lubricated, self-aligning pillow block bearings for smooth rotation and long service life
• CPC powder coat finish — chip resistant and rust inhibiting for extended field life

Compatibility

Designed for large-capacity dual hose reel applications; compatible with 1-inch ID hose up to 50 feet in length. Consult COXREELS 1275 Series documentation for specific fluid media ratings and motor options.

Installation Notes

Installation is typically performed by qualified industrial mechanics or service technicians. Power down all fluid supply and depressurize the system fully before connecting or disconnecting hose or swivel fittings. Secure the A-frame base to a structurally adequate mounting surface using the integrated mounting pattern in the steel base. When a motorized drive option is selected, follow applicable electrical codes and ensure the motor supply circuit is properly rated and protected before energizing.

Technical Specifications

• Hose Inner Diameter: 1 inch
• Hose Length Capacity: 50 feet
• Frame Material: 12-gauge welded steel
• Swivel Material: Solid brass
• Drive Options: Hand crank or motorized
• Length: 31 inches
• Width: 20 inches
• Height: 23 inches
• Weight: 68 pounds
• UPC: 674255839052

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1275-6-50-A
