Coxreels 1275-6-150-H Dual Hose Reel 150 Ft Hydraulic Motor

Product Description

The COXREELS 1275-6-150-H is a heavy-duty dual hose reel from the 1275 Series, engineered for large-capacity industrial and trade applications. It accepts hose with a 1-inch inner diameter and 1-7/16-inch outer diameter, with a capacity of 150 feet. The unit ships with a hydraulic motor drive and features dual plumbing with two swivel inlets and two low-profile outlet risers. The open drum slot and flat smooth hose wrap design prevent kinking and crimping during use. Licensed contractors and industrial maintenance crews are the primary installers of this class of reel.

This reel is suited for high-volume fluid transfer tasks in demanding environments, including commercial facilities, industrial plants, and fleet service operations. The dual hose configuration allows simultaneous delivery through two lines, making it appropriate for applications where independent fluid circuits are required. The hydraulic motor drive replaces manual effort on heavy or long hose runs, reducing operator fatigue in repetitive service cycles.

Key Features

• Dual plumbing with two machined solid-brass 90-degree full-flow NPT swivels for simplified seal maintenance and hose installation without removing the reel from its mount
• Two exclusive low-profile outlet risers with open drum slot design for a non-crimping, flat smooth hose wrap
• One-piece all CNC robotically welded 12-gauge steel A-frame base for superior rigidity and strength over bolted alternatives
• Heavy-duty CNC robotically spun and ribbed discs with rolled edges for enhanced strength, durability, hose protection, and operator safety
• Permanently lubricated self-aligning pillow block bearings for smooth rotation and long-term trouble-free operation
• CPC powder coat finish that is chip-resistant and rust-inhibiting for extended service life in harsh conditions

Compatibility

Designed as an OEM-style large-capacity dual hose reel for industrial and commercial fluid transfer systems requiring 1-inch ID hose up to 150 feet in length.

Installation Notes

Installation should be performed by a qualified technician familiar with hydraulic or fluid transfer systems. Shut off and depressurize all fluid supply lines before mounting or connecting the reel. The steel A-frame base includes a standard mounting pattern for secure attachment to a fixed surface. Consult applicable local codes and the hydraulic motor manufacturer specifications before completing the hydraulic drive connection.

Technical Specifications

• Hose Inner Diameter: 1 inch
• Hose Outer Diameter: 1-7/16 inches
• Hose Capacity: 150 feet
• Drive Type: Hydraulic motor
• Frame Material: 12-gauge steel, CNC robotically welded
• Finish: CPC powder coat, chip-resistant and rust-inhibiting
• Length: 37 inches
• Width: 28 inches
• Height: 31 inches
• Weight: 93 pounds
• UPC: 674255839311

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1275-6-150-H
