Coxreels 1275-6-150-EB Dual Hose Reel 150 Ft 24V Dc Motor

Product Description

The COXREELS 1275-6-150-EB is a large-capacity dual hose reel from the 1275 Series, engineered for demanding industrial and commercial applications where two hose lines must be managed from a single reel. The unit accepts hose with a 1-inch inner diameter and holds 150 feet of hose. It ships powered by a 24-volt DC, 1/3 HP reversible electric motor for consistent motorized rewind. Fabricated from 12-gauge steel with a CNC robotically welded one-piece frame, this reel is built to hold up in permanent installations where reliability and structural rigidity are non-negotiable.

The 1275-6-150-EB is suited for large-capacity plumbing, industrial fluid transfer, and similar professional installations requiring dual hose management. The open drum slot and dual low-profile outlet risers allow hose to wrap flat and smooth without crimping, making this reel appropriate for high-cycle service environments. Licensed contractors and facilities maintenance professionals handling large-diameter hose in fixed or vehicle-mount applications will find this reel a workable fit. No specific OEM model compatibility data was provided by the manufacturer for this listing.

Key Features

• Electric motorized rewind with 24-volt DC, 1/3 HP reversible motor for hands-free hose retrieval
• Dual plumbing with two machined solid-brass 90-degree full-flow NPT swivel inlets for simple seal maintenance without removing the reel from its mount
• Two exclusive low-profile outlet risers and open drum slot provide a non-crimping, flat smooth hose wrap
• One-piece all CNC robotically welded 12-gauge steel frame for superior structural rigidity over bolted designs
• Heavy-duty CNC robotically spun and ribbed discs with rolled edges for hose protection and operator safety
• Permanently lubricated, self-aligning pillow block bearings for smooth rotation and long service life
• Chip-resistant, rust-inhibiting CPC powder coat finish for extended durability in harsh environments

Compatibility

Designed as an OEM-style large-capacity dual hose reel replacement or new installation unit within the COXREELS 1275 Series product family, compatible with 1-inch ID hose applications up to 150 feet in length.

Installation Notes

Installation should be performed by a qualified technician familiar with industrial hose reel mounting and low-voltage electrical wiring. Disconnect and lock out all power sources before servicing the motor or electrical connections, and shut off fluid supply before connecting or removing hose lines. The steel base includes a pre-drilled mounting pattern for secure wall, floor, or vehicle-mount installation. Electrical wiring for the 24-volt DC motor circuit should comply with applicable NEC requirements for the installation environment.

Technical Specifications

• Hose Inner Diameter: 1 inch
• Hose Capacity: 150 feet
• Motor Voltage: 24 volts DC
• Motor Output: 1/3 HP reversible
• Frame Material: 12-gauge steel, CNC robotically welded
• Swivel Material: Solid brass, machined
• Finish: CPC powder coat
• Length: 37 inches
• Width: 28 inches
• Height: 31 inches
• Weight: 111 pounds
• UPC: 674255839298

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1275-6-150-EB
