Coxreels 1275-4-200-E Dual Hose Reel 200 Ft 12V Dc

Product Description

The COXREELS 1275-4-200-E is a heavy-duty dual hose reel built for large-capacity industrial and commercial applications. It accommodates hose with a 1/2 inch ID and holds up to 200 feet of hose. The reel features dual plumbing with two swivel inlets and two low-profile outlet risers that work with an open drum slot to deliver a non-crimping, flat smooth hose wrap. Power is provided by an onboard 12V DC, 1/3 HP reversible motor, though the unit can also be configured for hand-crank operation. The one-piece all-welded steel A-frame ensures structural rigidity without bolted joints. Licensed trades and industrial maintenance crews are the typical end users.

The 1275-4-200-E is suited for large-volume fluid transfer tasks in industrial plants, service garages, agricultural operations, and similar commercial environments where long hose runs and reliable retrieval are required. The dual-plumbing design supports simultaneous or split-flow configurations, making it a practical choice wherever a single-drum reel lacks the capacity or flow path flexibility needed for the job.

Key Features

• Dual plumbing with two machined solid-brass 90-degree full-flow NPT swivels for simple seal maintenance and hose installation without removing the reel from its mount
• Two low-profile outlet risers and open drum slot provide a non-crimping, flat smooth hose wrap that extends hose service life
• One-piece all-welded 12-gauge steel A-frame base with integrated mounting pattern for rigid installation and easy removal
• Heavy-duty CNC robotically spun and ribbed discs with rolled edges for strength, durability, hose protection, and operator safety
• Permanently lubricated, self-aligning pillow block bearings for smooth rotation and long service intervals
• 12V DC, 1/3 HP reversible motor with positive gear drive rewind for consistent, trouble-free retrieval
• CPC powder coat finish provides chip resistance and rust inhibition for extended service life in demanding environments

Compatibility

Designed for use with 1/2 inch ID hose up to 200 feet in length. Intended for large-capacity dual-hose reel applications in industrial, commercial, and heavy-service environments. Consult COXREELS documentation to confirm fitting thread size and motor voltage compatibility before installation.

Installation Notes

Installation of motorized hose reels should be performed by qualified personnel familiar with both fluid system plumbing and low-voltage DC wiring. Shut off all fluid supply lines and disconnect or de-energize the 12V DC power source before making any connections. Mount the reel to a structurally sound surface using the integrated base mounting pattern and appropriate fasteners rated for the combined weight of the reel and full hose load. Verify all NPT swivel connections are leak-free under operating pressure before returning the system to service.

Technical Specifications

• Hose ID: 1/2 inch
• Hose Capacity: 200 feet
• Motor: 12V DC, 1/3 HP reversible
• Frame Material: 12-gauge steel, one-piece welded A-frame
• Swivel Material: Solid brass, 90-degree full-flow NPT
• Finish: CPC powder coat
• Length: 37 inches
• Width: 21 inches
• Height: 21 inches
• Weight: 98 pounds
• UPC: 674255823396

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1275-4-200-E
