Coxreels 1275-4-200-A Dual Hose Reel 1/2 in 200 Ft

Product Description

The COXREELS 1275-4-200-A is a heavy-duty dual hose reel built for large-capacity industrial and commercial applications. It accommodates hose with a 1/2 inch inner diameter and 7/8 inch outer diameter up to 200 feet in length. The reel is available in hand crank or motorized configurations and features a one-piece all-welded steel A-frame base for maximum structural rigidity. Dual plumbing with two swivel inlets and two low-profile outlet risers ensures a non-crimping, flat hose wrap across the open drum slot. Licensed plumbers, industrial maintenance technicians, and fluid transfer specialists are the primary installers of this unit.

The 1275-4-200-A is suited for high-volume fluid transfer environments including industrial plants, fleet service facilities, agricultural operations, and commercial wash-down stations. The dual hose configuration supports applications where two separate hose runs are required from a single reel station. The hand crank or optional motorized drive makes it adaptable to locations where power availability varies. Its large drum capacity and robust frame make it a practical choice for permanent wall, floor, or ceiling mount installations in demanding service environments.

Key Features

• Dual plumbing with two machined solid brass 90-degree full-flow NPT swivels for easy seal maintenance and hose installation without removing the reel from its mount
• Two exclusive low-profile outlet risers with open drum slot design deliver a non-crimping, flat smooth hose wrap
• One-piece CNC robotically welded 12-gauge steel A-frame base provides superior rigidity compared to bolted frame designs
• Heavy-duty CNC robotically spun and ribbed discs with rolled edges for added strength, durability, hose protection, and operator safety
• Permanently lubricated, self-aligning pillow block bearings for smooth rotation and long-term trouble-free operation
• CPC powder coat finish offers chip resistance and rust inhibition for extended service life in harsh environments

Compatibility

Designed for use with 1/2 inch ID hose up to 200 feet in length as part of the COXREELS 1275 Series dual hose reel platform. Consult COXREELS documentation to confirm swivel fitting thread specifications and motor options for your specific installation.

Installation Notes

Installation of this hose reel should be performed by a qualified technician familiar with fluid transfer systems and appropriate mounting hardware for the intended surface type. Shut off all upstream fluid supply and depressurize the lines before connecting or disconnecting hose or swivel fittings. Ensure the mounting structure can support the combined weight of the reel and fully loaded hose. Local mechanical and plumbing codes may apply depending on the fluid media and facility type.

Technical Specifications

• Hose Inner Diameter: 1/2 inch
• Hose Outer Diameter: 7/8 inch
• Hose Capacity: 200 feet
• Frame Material: 12-gauge steel, CNC robotically welded
• Swivel Material: Solid brass
• Finish: CPC powder coat
• Length: 37 inches
• Width: 21 inches
• Height: 21 inches
• Weight: 71 pounds
• UPC: 674255823617

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1275-4-200-A
