Coxreels 1185-3328-BYXX Storage Hose Reel Steel

Product Description

The COXREELS 1185-3328-BYXX is a heavy-duty steel storage hose reel designed for industrial and trade applications where long runs of hose, cord, cable, wire, rope, tape, or chain need to be stored and retrieved efficiently. The reel uses a direct hand crank for mechanical retraction and features no swivel or riser, making it purpose-built for stationary or mobile storage duties. Key construction elements include CNC robotically spun and ribbed steel discs with rolled edges and a fully welded one-piece steel A-frame base. At 169 pounds and measuring 49 inches long by 32 inches wide by 32 inches tall, this is a substantial unit built for demanding service environments.

The 1185-3328-BYXX suits industrial, commercial, and municipal operations where large-diameter or long-length materials must be managed on fixed or vehicle-mounted installations. Typical applications include fire departments, utility crews, irrigation contractors, and industrial facilities that need a reliable, no-nonsense storage solution. The A-frame base includes a built-in mounting pattern for straightforward installation to a floor or vehicle platform, and the adjustable tension brake allows controlled payout speed without free-wheeling during operation or transport.

Key Features

• No swivel, no riser design keeps the reel focused on pure storage and retrieval of hose, cord, cable, wire, rope, tape, and chain
• CNC robotically spun and ribbed steel discs with rolled edges provide structural strength, hose protection, and operator safety
• One-piece fully welded 1/4-inch steel A-frame base eliminates bolted joints for superior structural integrity
• Adjustable tension brake controls draw speed and prevents free-wheeling during use, transport, and storage
• Permanently lubricated self-aligning pillow block bearings deliver smooth rotation and long service life
• CPC powder coat finish resists chips and rust for extended field durability

Compatibility

Designed as a stationary or mobile storage reel for long lengths of hose, collapsible hose, power cord, cable, rope, wire, barbed wire, tape, and chain in industrial and commercial service environments.

Installation Notes

Installation is typically performed by maintenance technicians or equipment riggers familiar with heavy industrial mounting. Power down or de-energize any adjacent equipment before mounting near electrical systems. The A-frame base mounting pattern should be secured to a structurally adequate surface rated for the combined weight of the reel and its loaded material. Follow applicable OSHA and facility safety guidelines when mounting to mobile units or vehicle platforms.

Technical Specifications

• Weight: 169 pounds
• Length: 49 inches
• Width: 32 inches
• Height: 32 inches
• Frame Material: Steel
• Frame Construction: One-piece fully welded 1/4-inch steel A-frame
• Retraction Method: Direct hand crank
• Bearing Type: Permanently lubricated self-aligning pillow block bearings
• Finish: CPC powder coat
• UPC: 674255837690

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1185-3328-BYXX
