Coxreels 1175-6-100-C-BYXX Storage Hose Reel Hand Crank

Product Description

The COXREELS 1175-6-100-C-BYXX is a heavy-duty storage hose reel built for trade and industrial professionals who need a reliable, stationary or mobile solution for managing long lengths of hose, cord, cable, rope, wire, tape, or chain. The reel uses a front bevel-geared hand crank for mechanical retraction and features CNC robotically spun and ribbed steel discs with rolled edges for added strength and operator safety. Weighing 73 pounds and measuring 29.5 inches long by 25 inches wide by 26.5 inches tall, this unit is sized for demanding storage tasks in shops, job sites, and service vehicles.

This storage reel is designed for professional use in industrial, commercial, and trade environments where large quantities of hose, electrical cord, cable, wire, rope, barbed wire, tape, or chain must be stored and retrieved efficiently. Unlike standard reels, the 1175-6-100-C-BYXX has no swivel and no riser, making it purpose-built for storage and long-length management rather than active fluid or air delivery. It suits both stationary mounting and mobile unit configurations, with a mounting pattern integrated into the steel base for straightforward installation and removal.

Key Features

• CNC robotically spun and ribbed steel discs with rolled edges for durability, hose protection, and operator safety
• All-welded one-piece 0.25-inch steel A-frame base for superior structural rigidity without bolted joints
• Front bevel-geared hand crank enables smooth, controlled mechanical retraction
• Adjustable tension brake controls draw speed and prevents free-wheeling during operation, transport, or storage
• Permanently lubricated, self-aligning pillow block bearings for smooth rotation and low maintenance
• CPC powder coat finish resists chips and rust for long service life in demanding environments

Compatibility

Designed as an OEM-style storage reel suitable for use with hose, collapsible hose, power cord, cable, rope, wire, barbed wire, tape, and chain in stationary or mobile reel applications.

Installation Notes

Installation is typically performed by maintenance technicians or trade professionals using standard hand tools. Power down or disconnect any associated equipment before mounting or servicing the reel. The integrated mounting pattern in the steel base should be used to secure the unit to a stable surface per applicable workplace safety guidelines. Do not exceed the rated capacity of the reel or use it for active fluid delivery, as this unit has no swivel or riser.

Technical Specifications

• Weight: 73 pounds
• Length: 29.5 inches
• Width: 25 inches
• Height: 26.5 inches
• Frame Material: Steel
• Frame Construction: All-welded one-piece A-frame, 0.25-inch steel
• Retraction Method: Hand crank (front bevel geared)
• Finish: CPC powder coat
• UOM: Each

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1175-6-100-C-BYXX
