Coxreels 1125PCL-8M-E Cord Reel 250 Ft Motor Drive

Product Description

The COXREELS 1125PCL-8M-E is a heavy-duty motorized cord reel built for professional electrical power distribution in demanding jobsite and industrial environments. It handles long runs of 12/3 or 10/3 gauge SO-type power cord up to 250 feet and is driven by a 12-volt DC, 1/3 HP reversible motor for powered retraction. The all-welded steel A-frame construction and permanently lubricated pillow block bearings give this reel the structural integrity required for continuous heavy-duty use. A drum-located slip ring assembly with a removable access panel simplifies routine maintenance without dismounting the unit. Licensed electricians and industrial maintenance technicians are the primary installers.

The 1125PCL-8M-E suits applications where long cord management and motorized retrieval are required, including construction sites, industrial facilities, maintenance shops, and service vehicles. The 250-foot cord capacity makes it practical for large-footprint work areas where portable power must reach distant equipment or workstations. The motor drive eliminates manual crank effort on full-load retraction, reducing fatigue during repeated daily use. The reel is sold as an individual unit and is appropriate for permanent mounting or structured mobile installations.

Key Features

• Motorized retraction via a 12-volt DC, 1/3 HP reversible motor for powered cord retrieval
• Drum-located slip ring assembly with removable access panel — no dismounting required for maintenance
• All-welded one-piece 12-gauge steel A-frame base provides superior structural rigidity over bolted alternatives
• Permanently lubricated, self-aligning pillow block bearings at each drum end for smooth, trouble-free rotation
• Integrated anti-rotation cable keeper prevents the 5-foot lead cable from whipping or twisting during operation
• CNC robotically spun and ribbed discs with rolled edges for cord protection and operator safety
• CPC powder coat finish resists chipping and rust for extended service life in harsh conditions

Compatibility

Designed to handle 12/3 gauge or 10/3 gauge SO-type power cord up to 250 feet in length. Part of the COXREELS 1125PCL Series of professional motorized cord reels.

Installation Notes

Installation should be performed by a qualified electrician in accordance with applicable NEC requirements. Disconnect and lock out all power sources before servicing the slip ring assembly or motor connections. Ensure the mounting surface can support the loaded weight of the reel and full cord capacity before securing the base. Do not exceed the cord gauge or length ratings specified for this reel model.

Technical Specifications

• Cord Capacity: 250 feet
• Compatible Cord Gauges: 12/3 or 10/3 SO-type power cord
• Drive Type: Motor drive, 12 volts DC, 1/3 HP reversible
• Frame Material: 12-gauge welded steel
• Lead Cable Length: 5 feet
• Length: 25.5 inches
• Width: 22 inches
• Height: 22 inches
• Weight: 48 pounds
• Finish: CPC powder coat
• UPC: 674255924222

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1125PCL-8M-E
