Coxreels 1125PCL-8M-C Cord Reel 250 Ft Hand Crank Steel

Product Description

The COXREELS 1125PCL-8M-C is a heavy-duty hand crank cord reel built for professional trade environments where long cord runs and repeated daily use demand reliable, low-maintenance equipment. Designed for 12/3 or 10/3 gauge SO-type power cord up to 250 feet, this reel uses a drum-located slip ring assembly that allows routine maintenance without removing the reel from its mount. The all-welded 12-gauge steel A-frame base provides a rigid, warp-resistant structure. At 35 pounds, this reel is built to stay fixed in place and handle the physical stress of demanding job sites. Electricians and industrial maintenance technicians are the primary installers.

This cord reel is suited for commercial and industrial applications where long-length power cord management is required. Typical installations include maintenance bays, manufacturing facilities, warehouses, and job site service vehicles where a 250-foot reach of SO-type cord is needed. The front bevel-geared hand crank provides controlled mechanical retraction, making it practical for one-person operation even with full cord load. The adjustable tension brake prevents free-wheeling during payout, keeping the cord under control at all times.

Key Features

• Drum-located slip ring assembly with removable access panel — no need to dismount the reel for routine maintenance
• CNC robotically spun and ribbed steel discs with rolled edges for strength, cord protection, and operator safety
• One-piece all-welded 12-gauge steel A-frame base with integrated mounting pattern for secure installation and easy removal
• Permanently lubricated, self-aligning pillow block bearings at each drum end for smooth rotation in heavy-duty conditions
• Integrated anti-rotation cable keeper prevents the 5-foot lead cable from whipping or twisting
• CPC powder coat finish provides chip resistance and rust inhibition for long service life
• Adjustable tension brake and front bevel-geared crank for controlled cord retraction

Compatibility

Designed for use with 12/3 or 10/3 gauge SO-type power cord up to 250 feet in length. Part of the COXREELS 1125PCL Series of professional-grade hand crank cord reels.

Installation Notes

Installation is typically performed by a licensed electrician or qualified maintenance technician. Disconnect all power sources before servicing the slip ring assembly or making any electrical connections to the reel. Mount the reel to a structurally sound surface using the integrated base mounting pattern and appropriate fasteners for the substrate. Verify cord gauge and length are within the rated specifications for this reel before wiring.

Technical Specifications

• Cord Capacity: 250 feet
• Compatible Cord Gauge: 12/3 or 10/3 SO-type power cord
• Drive Type: Hand crank (front bevel-geared)
• Frame Material: 12-gauge welded steel
• Length: 25.5 inches
• Width: 22 inches
• Height: 22 inches
• Weight: 35 pounds
• Finish: CPC powder coat (chip-resistant, rust-inhibiting)
• UOM: Each
• UPC: 674255924215

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1125PCL-8M-C
