Coxreels 1125PCL-8-A Cord Reel 250 Ft Motor Drive

Product Description

The COXREELS 1125PCL-8-A is a heavy-duty motorized cord reel engineered for professional electrical service applications. Built on an all-welded steel A-frame base, it handles long runs of 12/3 or 10/3 gauge SO-type power cord up to 250 feet. The drum-located slip ring assembly allows routine maintenance without removing the reel from its mount, keeping downtime to a minimum. Permanently lubricated, self-aligning pillow block bearings at each end of the drum ensure smooth rotation under continuous heavy-duty use. An integrated aluminum body, 4-vane air motor drives cord retrieval. The unit ships at 43 pounds and measures 25.5 inches long by 22 inches wide by 22 inches tall.

This cord reel is suited for industrial, commercial, and trade environments where long cord lengths must be managed safely and efficiently. Typical installations include job site power distribution, maintenance facilities, manufacturing floors, and service bays where repeated cord deployment and retrieval is part of daily workflow. Electricians, maintenance technicians, and industrial service crews are the primary installers. The A-frame base mounting pattern allows the reel to be fixed to floors, walls, or overhead structures depending on the application.

Key Features

• Drum-located slip ring assembly with removable access panel for in-place routine maintenance
• CNC robotically spun and ribbed disc flanges with rolled edges for cord protection and operator safety
• One-piece, all-welded 1/4-inch steel A-frame base for superior structural rigidity
• Permanently lubricated, self-aligning pillow block bearings for smooth, trouble-free rotation
• Integrated anti-rotation cable keeper prevents the 5-foot lead cable from whipping or twisting
• Aluminum body, 4-vane air motor drive with chip-resistant, rust-inhibiting CPC powder coat finish

Compatibility

Designed to handle 12/3 gauge or 10/3 gauge SO-type power cord up to 250 feet in length. Part of the COXREELS 1125PCL Series of motorized cord reels.

Installation Notes

Installation should be performed by a qualified electrician in accordance with applicable NEC requirements. Disconnect and lock out all power sources before servicing the slip ring assembly or any electrical connections. Ensure the mounting surface and fasteners are rated for the combined weight of the reel and fully loaded cord. Do not exceed the cord gauge and length specifications for this model.

Technical Specifications

• Cord Capacity: 250 feet
• Compatible Cord Gauge: 12/3 or 10/3 SO-type
• Drive Type: Air motor, aluminum body, 4-vane
• Frame Material: 1/4-inch welded steel
• Finish: CPC powder coat, chip-resistant and rust-inhibiting
• Length: 25.5 inches
• Width: 22 inches
• Height: 22 inches
• Weight: 43 pounds

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1125PCL-8-A
