Coxreels 1125P-4-8 Pure Flow Hose Reel 1/2 in 150 Ft

Product Description

The COXREELS 1125P-4-8 is a spring-rewind hose reel from the Pure Flow series, engineered for applications that demand a clean, non-contaminated fluid path. The reel features an all-stainless-steel air and fluid path, including a stainless steel 90-degree full-flow NPT swivel inlet lubricated with non-toxic, food-quality grease. It accommodates hose with a 1/2 inch inner diameter and up to 150 feet in length, making it well-suited for storing and deploying breathing air lines or potable water hose in professional service environments. The unit weighs 37 pounds and measures 19.5 inches long, 18 inches wide, and 20 inches tall.

The 1125P-4-8 is designed for use in residential, commercial, and industrial settings where sanitized fluid transfer is required. Typical applications include low- and high-pressure respiratory air systems, drinking water supply lines, and any hose service where fluid contamination must be prevented. The spring-rewind retraction mechanism provides fast, controlled hose retrieval. HVAC service technicians, plumbers, safety professionals, and facility maintenance crews are the primary installers and users of this reel.

Key Features

• All-stainless-steel air and fluid path with stainless steel 90-degree full-flow NPT swivel inlet for corrosion resistance and clean fluid transfer
• Non-toxic, food-quality grease in swivel bearings suitable for potable water and breathing air service
• Heavy-duty CNC robotically spun and ribbed discs with rolled edges for hose protection and operator safety
• Exclusive low-profile outlet riser and open drum slot design prevents hose kinking and promotes flat, smooth hose wrap
• One-piece CNC robotically welded 12-gauge steel A-frame base with integrated mounting pattern for secure installation and easy removal
• CPC powder-coat finish resists chipping and rust; adjustable tension brake prevents free-wheeling during deployment

Compatibility

Designed for use with 1/2 inch ID hose up to 150 feet in length in breathing air and potable water hose reel applications requiring a stainless steel, food-grade fluid path.

Installation Notes

Install by a qualified plumber, HVAC technician, or safety equipment professional. Mount the reel to a solid surface using the integrated mounting pattern in the steel A-frame base, ensuring the surface can support the loaded weight of the reel and hose. Shut off all system pressure and depressurize the hose line before connecting or disconnecting fittings. Follow all applicable local codes and OSHA requirements when installing reels used in respiratory air or potable water service.

Technical Specifications

• Hose Inner Diameter: 1/2 inch
• Hose Outer Diameter: 7/8 inch
• Maximum Hose Length: 150 feet
• Retraction Type: Spring Rewind
• Swivel Material: Stainless Steel
• Fluid Path Material: Stainless Steel
• Frame Material: 12-Gauge Steel, CNC Robotically Welded
• Finish: CPC Powder Coat
• Length: 19.5 inches
• Width: 18 inches
• Height: 20 inches
• Weight: 37 pounds
• UPC: 674255829138

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1125P-4-8
