Coxreels 1125P-4-6 Pure Flow Hose Reel 1/2 Inch 100 Ft

Product Description

The COXREELS 1125P-4-6 is a Pure Flow series spring-rewind hose reel engineered for clean-fluid applications including breathing air and potable water service. The reel features an all-stainless-steel air and fluid path with a stainless-steel 90-degree full-flow NPT swivel inlet, eliminating metallic contamination risk. CNC robotically spun and ribbed discs with rolled edges give the drum its structural rigidity, while a CPC powder coat finish resists chipping and rust. At 36 pounds and measuring 19.5 inches long by 18 inches wide by 20 inches tall, it is sized for fixed wall or floor mounting in service bays, industrial facilities, and fire or EMS stations.

The 1125P-4-6 is suited for residential and commercial installations wherever sanitized, non-contaminated fluid transfer is required. Typical applications include respiratory air hose management for low- and high-pressure breathing air systems, potable water distribution at service points, and food-grade or pharmaceutical fluid lines. The exclusive low-profile outlet riser and open drum slot design promotes a flat, non-crimping hose wrap across the full 100-foot hose length, protecting hose integrity over repeated retraction cycles. Licensed trades including plumbers, HVAC technicians, and industrial hygienists commonly specify this reel for code-sensitive fluid systems.

Key Features

• All-stainless-steel fluid path and swivel inlet with non-toxic, food-quality grease for contamination-free fluid transfer
• CNC robotically spun and ribbed discs with rolled edges for structural strength and hose protection
• Low-profile outlet riser and open drum slot for non-crimping, flat hose wrap
• One-piece CNC robotically welded 12-gauge steel A-frame base with integrated mounting pattern
• Adjustable tension brake prevents free-wheeling; direct hand crank enables easy mechanical retraction
• Long-lasting CPC powder coat finish resists chipping and rust

Compatibility

Designed as an OEM-style replacement or new-installation reel for systems requiring sanitized, non-contaminated hose management, including breathing air and potable water applications with 1/2 inch ID hose up to 100 feet in length.

Installation Notes

Installation is typically performed by licensed plumbers, mechanical contractors, or qualified industrial maintenance technicians. Shut off all fluid supply and depressurize the line fully before connecting or disconnecting the swivel inlet. Mount to a structurally sound wall, floor, or ceiling surface using the integrated base mounting pattern in accordance with applicable IPC or IFGC guidelines and local codes. Do not exceed the rated hose length or connect hose with an ID other than 1/2 inch without verifying system compatibility.

Technical Specifications

• Hose ID: 1/2 inch
• Hose OD: 7/8 inch
• Hose Length Capacity: 100 feet
• Retraction Type: Spring rewind
• Fluid Path Material: Stainless steel
• Frame Material: 12-gauge steel, CNC robotically welded
• Finish: CPC powder coat
• Length: 19.5 inches
• Width: 18 inches
• Height: 20 inches
• Weight: 36 pounds
• UPC: 674255829121

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1125P-4-6
