Coxreels 1125P-4-6-H Pure Flow Hose Reel 1/2 Inch Id

Product Description

The COXREELS 1125P-4-6-H is a Pure Flow series hose reel designed for clean-fluid applications including breathing air, potable water, and other sanitary fluid transfer systems. The reel features an all-stainless steel air and fluid path with a stainless steel 90-degree full-flow NPT swivel inlet, ensuring non-contaminated fluid transfer. The drum and discs are CNC robotically spun and ribbed with rolled edges for structural strength and hose protection. A CPC powder coat finish resists chipping and rust. At 42 pounds, this is a heavy-duty unit suited for permanent installation by licensed plumbers, mechanical contractors, or safety equipment technicians.

The 1125P-4-6-H is built for applications requiring sanitized, non-contaminated fluid transfer. Common uses include respiratory air hose storage for low- and high-pressure breathing systems, potable water lines for drinking water systems, and food-grade fluid handling environments. The spring rewind retraction makes it practical in fixed service bays, wash-down stations, and industrial safety stations where quick hose retrieval is needed. The low-profile outlet riser and open drum slot design supports flat, non-crimping hose wrap, extending hose service life.

Key Features

• Stainless steel air and fluid path with stainless steel 90-degree full-flow NPT swivel inlet for non-toxic, contamination-free fluid transfer
• CNC robotically spun and ribbed discs with rolled edges for strength, durability, and operator safety
• Exclusive low-profile outlet riser and open drum slot design prevents hose crimping and promotes flat hose wrap
• One-piece CNC robotically welded 12-gauge steel A-frame base with integrated mounting pattern for secure installation and easy detachment
• Spring rewind retraction with adjustable tension brake to prevent free-wheeling
• Long-lasting CPC powder coat finish resists chips and rust

Compatibility

Designed for use in Pure Flow series installations requiring sanitary fluid transfer, including breathing air systems and potable water applications. Accepts 1/2 inch inner diameter hose with a 7/8 inch outer diameter.

Installation Notes

Installation should be performed by a qualified plumber or mechanical contractor familiar with sanitary fluid system requirements. Shut off the fluid supply and depressurize the line completely before connecting or disconnecting the reel. Secure the A-frame base to a structurally sound mounting surface using the integrated mounting pattern. Verify all swivel connections are properly threaded and leak-tested before returning the system to service.

Technical Specifications

• Hose Inner Diameter: 1/2 inch
• Hose Outer Diameter: 7/8 inch
• Frame Material: 12-gauge steel with CPC powder coat finish
• Fluid Path Material: Stainless steel
• Retraction Type: Spring rewind
• Length: 25.5 inches
• Width: 22 inches
• Height: 22 inches
• Weight: 42 pounds
• UPC: 674255856134

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1125P-4-6-H
