Coxreels 1125-5-100-AB Hose Reel 3/4 in Id 100 Ft

Product Description

The COXREELS 1125-5-100-AB is a heavy-duty hand crank hose reel from the 1125 Series, engineered for demanding industrial and trade applications. It accepts 3/4-inch ID hose with a 1-1/4-inch OD and holds up to 100 feet of hose. The reel is built on a one-piece all-welded 12-gauge steel A-frame base with permanently lubricated, self-aligning pillow block bearings for smooth, consistent rotation. A front bevel-geared crank provides mechanical retraction, and the low-profile outlet riser with open drum slot design ensures a flat, non-crimping hose wrap. Weighing 50 pounds, this reel is suited for installation by maintenance technicians, fleet service operations, and industrial facilities.

The 1125-5-100-AB is designed for industrial and commercial service environments where reliable hose management and extended service life are required. The open drum slot layout accommodates flat, smooth hose wrapping without kinking, making it appropriate for fluid transfer, wash-down stations, lubrication systems, and similar fixed-mount hose delivery applications. The reel ships as a single unit and is compatible with standard NPT hose and plumbing connections.

Key Features

• 3/4-inch ID inlet accepts standard NPT hose connections via a machined solid-brass 90-degree full-flow swivel — no reel dismounting required for hose changes
• One-piece all-welded 12-gauge steel A-frame base provides superior structural rigidity over bolted designs
• CNC robotically spun and ribbed discs with rolled edges for strength, durability, and operator safety
• Low-profile outlet riser and open drum slot design prevents hose crimping and promotes flat, even hose wrap
• Permanently lubricated, self-aligning pillow block bearings for smooth rotation and long service life
• CPC powder coat finish resists chips and rust for extended service in demanding environments

Compatibility

Designed as an OEM-style fixed-mount hose reel for industrial and commercial fluid transfer systems accepting 3/4-inch ID hose with standard NPT connections.

Installation Notes

Installation is typically performed by industrial maintenance technicians or plumbing professionals. Power down or depressurize any connected fluid supply before mounting or connecting hose. The A-frame base mounting pattern allows direct bolt-down installation; consult the reel mounting template for fastener placement. Follow applicable facility plumbing codes and manufacturer torque guidelines for NPT fittings when making hose connections.

Technical Specifications

• Hose ID: 3/4 inch
• Hose OD: 1-1/4 inch
• Hose Capacity: 100 feet
• Frame Material: 12-gauge steel, all-welded
• Swivel Material: Solid brass
• Swivel Type: 90-degree full-flow NPT
• Length: 25.5 inches
• Width: 22 inches
• Height: 22 inches
• Weight: 50 pounds
• Finish: CPC powder coat
• UPC: 674255851399

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1125-5-100-AB
