Coxreels 1125-4-100-SP Ss Hand Crank Hose Reel 1/2in 100ft

Product Description

The COXREELS 1125-4-100-SP is a stainless steel hand crank hose reel built for demanding service environments where corrosion, contamination, and chemical exposure are ongoing concerns. Part of the COXREELS 1125-SS Series, it features an electro-polished stainless steel construction with fully stainless fluid paths. The reel accepts 1/2 inch ID hose with a 7/8 inch OD and handles 100 feet of hose capacity. It is designed for stationary mounting and direct hand crank retrieval. Licensed plumbers, industrial maintenance technicians, and sanitation crews are the primary installers and operators.

This hose reel is suited for food and chemical processing facilities, marina environments, and any application where rust, corrosion, and contamination cannot be tolerated. The stainless steel fluid path and electro-polished finish make it appropriate for washdown stations, chemical dispensing lines, and marine dockside water service. It is not intended for standard residential water supply use where a carbon steel or aluminum reel would suffice.

Key Features

• Electro-polished stainless steel construction with stainless steel fluid paths for non-corrosive, contamination-resistant performance
• Machined stainless steel 90-degree full-flow NPT swivel inlet for external fluid path integrity
• Heavy duty CNC robotically spun and ribbed stainless steel discs with rolled edges for strength, durability, and hose protection
• Exclusive low-profile stainless steel outlet riser and open drum slot design prevents hose crimping and promotes flat, smooth wrap
• One-piece CNC robotically welded 1/4 inch stainless steel A-frame base with integrated mounting pattern for secure installation and easy detachment
• Permanently lubricated, self-aligning pillow block bearings and adjustable tension brake for smooth rotation and controlled payout

Compatibility

Designed for use with 1/2 inch ID, 7/8 inch OD hose up to 100 feet in length. Suitable for fluid systems requiring stainless steel wetted components, including food processing, chemical handling, and marine washdown applications.

Installation Notes

Installation is typically performed by licensed plumbers or qualified industrial maintenance technicians. Shut off the fluid supply and depressurize the line completely before mounting or connecting the reel. Secure the A-frame base to a structurally sound surface using appropriately rated fasteners through the integrated mounting pattern. Verify all NPT inlet connections are properly sealed and leak-tested before returning the system to service.

Technical Specifications

• Hose ID: 1/2 inch
• Hose OD: 7/8 inch
• Hose Capacity: 100 feet
• A-Frame Base Thickness: 1/4 inch stainless steel
• Weight: 36 pounds
• Material: Electro-polished stainless steel
• Inlet Type: 90-degree full-flow NPT swivel
• Drive Type: Direct hand crank
• Brake: Adjustable tension brake
• UOM: Each

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1125-4-100-SP
