Coxreels 1125-4-100-EA-SP Ss Hose Reel 1/2 in 100 Ft

Product Description

The COXREELS 1125-4-100-EA-SP is a stainless steel hand crank hose reel built for demanding service environments where corrosion resistance and fluid path cleanliness are non-negotiable. The reel features a 1/2 inch inner diameter hose capacity, accepts hose up to 7/8 inch outer diameter, and handles 100 feet of hose. The drum, discs, swivel inlet, and outlet riser are all constructed from electro-polished stainless steel, keeping the entire fluid path free of rust and contamination. Licensed trades and facility maintenance professionals working in food processing, chemical handling, or marine environments specify this reel where carbon steel alternatives are unsuitable.

This reel is designed for fixed-mount installations in facilities requiring non-corrosive hose management. Typical applications include food and beverage processing plants, chemical transfer stations, marinas, and washdown stations where moisture, cleaning agents, or corrosive atmospheres are present. The hand crank drive suits controlled, low-frequency dispensing operations. The adjustable tension brake prevents free-wheeling during retraction, which matters in tight or busy work areas where an unsecured hose end presents a hazard.

Key Features

• Electro-polished stainless steel construction throughout drum, discs, swivel, and outlet riser for full corrosion resistance
• Machined stainless steel 90-degree full-flow NPT swivel inlet for non-corrosive external fluid path
• CNC robotically spun and ribbed stainless steel discs with rolled edges for hose protection and operator safety
• Low-profile stainless steel outlet riser with open drum slot design provides flat, non-crimping hose wrap
• One-piece CNC robotically welded 1/4 inch stainless steel A-frame base with integrated mounting pattern for secure installation
• Permanently lubricated, self-aligning pillow block bearings for smooth rotation and long service life
• Adjustable tension brake prevents free-wheeling during hose deployment

Compatibility

Designed for use with 1/2 inch inner diameter hose up to 7/8 inch outer diameter and accommodates up to 100 feet of hose length. Suitable for fluid transfer applications in food processing, chemical processing, marine, and washdown environments requiring stainless steel construction.

Installation Notes

Installation should be performed by a qualified technician familiar with fluid handling equipment and the requirements of the applicable facility or plumbing code. Mount the reel to a structurally sound surface using the integrated base mounting pattern, ensuring the mounting substrate can support the reel and hose assembly at full load. Shut off the fluid supply and depressurize the line before connecting or disconnecting the swivel inlet. Verify all NPT thread connections are sealed appropriately for the fluid and pressure being handled before returning the system to service.

Technical Specifications

• Hose Inner Diameter: 1/2 inch
• Hose Outer Diameter: 7/8 inch
• Hose Length Capacity: 100 feet
• Frame Material: Stainless steel, 1/4 inch wall, CNC welded A-frame
• Disc Construction: CNC robotically spun stainless steel with ribbing and rolled edges
• Swivel Inlet: Machined stainless steel 90-degree full-flow NPT
• Drive Type: Hand crank with adjustable tension brake
• Finish: Standard unpolished as-manufactured stainless steel
• Weight: 62 pounds
• UPC: 674255855786

Standard Information

• Brand: COXREELS
• Manufacturer Part Number: 1125-4-100-EA-SP
