Product Description
The Honeywell MS4120F1006 Two-Position Actuator is a fast-acting, spring-return direct coupled actuator designed for fire and smoke dampers. This actuator operates on 120 volts and features a robust 80 lb-in torque mechanism. Ideal for HVAC systems, it ensures efficient on/off control and has a reversible mounting option for both clockwise and counterclockwise spring rotation.
- 80 lb-in minimum driving torque
- Reversible mounting for clockwise or counterclockwise rotation
- Fifteen-second spring return timing
Product Highlights
Honeywell MS4120F1006 actuator offers powerful torque and versatile mounting for fire and smoke damper applications. It features an integral spring return for reliable performance and no special cycling during long-term holding.
Product Information
Standard Information
-
Manufacturer: Honeywell
-
Brand: Honeywell
-
MPN: MS4120F1006
Technical Specifications
-
Voltage: 120 volts
-
Connector Type: Clamp
-
Number of Poles: 1
-
Number of Positions: 2
-
Driving Torque: 80 lb-in
-
Spring Return Timing: 15 seconds
-
Operating Temperature: -40 F to 130 F
-
Mounting Type: Direct Coupled
