Copperfit 5952LF Brass Ball Valve Hose Bib 3/4in Mipt

Product Description

The COPPERFIT 5952LF is a 3/4-inch MIPT brass ball valve hose bib designed for controlling water flow at hose connection points in residential and light commercial plumbing systems. The quarter-turn ball valve mechanism provides fast, reliable shutoff with minimal pressure drop. Constructed from brass, this hose bib is built to handle standard water supply pressures and resist corrosion in both indoor and outdoor installations. Licensed plumbers and experienced pipe fitters are the typical installers for this type of fitting in new construction and retrofit applications.

This hose bib is suited for use at exterior wall connections, utility rooms, irrigation tie-ins, and other locations requiring a threaded male-inlet ball valve with a hose outlet. The 3/4-inch MIPT connection threads directly into standard female-threaded pipe fittings or tees. It is appropriate for residential potable water systems as well as light commercial plumbing where a compact, quarter-turn shutoff at a hose connection is required.

Key Features

• 3/4-inch MIPT inlet for direct connection to standard female-threaded pipe fittings
• Brass body construction for corrosion resistance and durability in water service
• Quarter-turn ball valve operation for fast full-open or full-closed shutoff
• Hose bib outlet accommodates standard garden hose or utility hose connections

Compatibility

Designed as an OEM-style replacement or new-installation brass ball valve hose bib for standard 3/4-inch MIPT threaded plumbing connections in residential and light commercial water supply systems.

Installation Notes

Installation should be performed by a licensed plumber in accordance with applicable local plumbing codes and IPC guidelines. Shut off the main water supply and relieve system pressure before installing or replacing this valve. Apply thread sealant tape or pipe dope to the MIPT threads before threading into the female fitting — do not overtighten, as brass fittings can crack under excessive torque. After installation, restore water pressure and inspect for leaks at the threaded joint before returning the system to service.

Technical Specifications

• Connection Size: 3/4 inches
• Connection Type: MIPT (Male Iron Pipe Thread)
• Body Material: Brass
• Valve Type: Ball Valve
• Weight: 0.7 pounds
• UPC: 812042027712

Standard Information

• Brand: COPPERFIT
• Manufacturer Part Number: 5952LF
