Copeland ZR21K5E-PFJ-800 Scroll Compressor

Product Description

The Copeland ZR21K5E-PFJ-800 is a scroll compressor ideal for air conditioning applications. This model works with R22 and R407C refrigerants and requires polyol ester (POE) oil. A capacitor is necessary for operation, but is sold separately. This compressor caters to both residential and light commercial markets. It includes a sweat connection type with a three-quarter-inch suction and a half-inch discharge.

• Works with R22 and R407C refrigerants
• Requires capacitor (not included)
• Polyol ester (POE) oil compatible

Product Highlights

This model serves as a robust option for cooling needs in homes and small businesses.

Product Information

Standard Information

• Brand: Copeland
• Manufacturer Part Number: ZR21K5E-PFJ-800

Technical Specifications

• Compressor Type: Scroll
• Application: A/C
• Refrigerant: R22, R407C
• Capacity (BTUH): 21000
• Voltage: 265-277/1
• Power Phase: 1-Phase
• Horsepower: 1 3/4
• Connection Type: Sweat
• Connection Suction (Inches): 3/4
• Connection Discharge (Inches): 1/2
• Oil: Polyol Ester
• Oil Recharge (Ounces): 19
• Displacement (CFH): 214.8615
• Displacement (Cubic Inches/Rev): 1.768
• Rated Load Amps: 10.4
• Run Capacitor (Microfarad x Voltage): 35 x 370
• Height (Inches): 15.86
• Mount (Inches): 7.5 x 7.5
• Country of Origin: US
• Application by Refrigerant: A/C - R22, A/C - R407C
• Amperage: 12
• Energy Efficiency Ratio (EER): 9.9
