Copeland ZP182KCETFD scroll compressor 15.0 hp

Product Description

The Copeland ZP182KCETFD is a 15.0 nominal HP scroll compressor designed for R410A refrigeration systems in air conditioning applications. This 3-phase unit operates on multiple voltages including 460V, 200-230V, 380V, and 208-230V at 60Hz, delivering a cooling capacity of 183,000 BTU/h. It features a cooling efficiency (EER) of 11.2, making it suitable for various HVAC installations requiring reliable performance.

• Designed for R410A refrigeration type in air conditioning applications.
• Multi-voltage 3-phase operation (460V, 200-230V, 380V, 208-230V; 60Hz).
• Provides a cooling capacity of 183,000 BTU/h (53,500 W) with 15.0 nominal HP.

Product Highlights

Efficient 15.0 HP scroll compressor for R410A air conditioning systems.

Product Information

Standard Information

• Brand: COPELAND
• Manufacturer Part Number: ZP182KCETFD

Technical Specifications

• Refrigeration Type: R410A
• EER: 11.2
• Cooling Capacity (BTU/h): 183,000
• Input Voltage: 460V / 200-230V / 380V / 208-230V; 60Hz
• Phase: 3
• Application: Air Conditioning
• Nominal Horsepower: 15.0
• Cooling Capacity (W): 53,500
• Input Power: 16,300 W
• Operating Current: 26.3 A
• Coefficient of Performance (COP): 3.28
• Displacement: 167.2 cc/Rev.
• Oil Quantity: 3.25 L
• Net Weight: 66.2 Kg
• Locked Rotor Amps (LRA): 179.0 A
• Sound Pressure at 1m: 69.0 dBA
