Copeland Comfort Control 1F98EZ-1441 Blue Easy Install Universal 4-Wire Programmable Touchscreen Thermostat w Outdoor Remote Sensor

Product Description

The Copeland Comfort Control 1F98EZ-1441 is a universal thermostat designed for effective HVAC management. This model quickly converts single-stage installations into multi-stage, heat pump, or dual fuel systems using existing four wires. It features a touchscreen interface with scrolling text for easy navigation, alongside a menu-driven setup accompanied by audio prompts to confirm your touch entries.

• Upgrades existing 4-wire systems to support multi-stage heating and cooling.
• User-friendly interface with touch screen and audio prompts.
• Includes outdoor sensor for enhanced temperature control.

Product Highlights

This thermostat offers dehumidification and humidification control, programmable fan options, and compatibility with dual fuel heat pump systems.

Product Information

Standard Information

• Application: Electric, Gas, Oil, Humidity Control
• Power: Hardwired

Technical Specifications

• Cooling Stage: 2
• Heating Stage: 4 HP, 2 Conventional
• Programmability: 7-Day Programmable or Non-Programmable
• Voltage: 20 to 30 VAC
• Terminal Load: 1.5 A per terminal, 2.5 A maximum load (all terminals combined)
• Setpoint Range: 45 to 99°F (7 to 37°C)
• Rated Differential: Heat 0.6°F; Cool 1.2°F
• Operating Ambient: 32 to 105°F (0 to 41°C)
