Copeland Comfort Control 13S16-102

Product Description

The Copeland Comfort Control 13S16-102 is a three-quarter inch sweat zone valve. It offers a two-way design for straight-through positioning. The valve is equipped with a stainless steel return spring, ensuring reliable fail-safe operation. It also features a manual lever, allowing easy opening of normally closed valves. An auxiliary switch is included for additional functionality. The valve has a molded plastic cover for moisture protection.

• Two-way, straight-through design
• Includes sweat connection
• Normally closed operation with auxiliary switch

Product Highlights

This zone valve is made with a swing-type ball valve from EPDM and operates via an electric synchronous motor with a spring return.

Product Information

Standard Information

• Brand: Copeland Comfort Control
• MPN: 13S16-102

Technical Specifications

• Voltage: 24 VAC
• Frequency: 50/60 Hz
• Connection: 18 leads
• Flow Capacity: 3.5 Cv
• Close-off Pressure: 20 PSI
• Maximum Pressure: 142 PSI
• Maximum Temperature: 110 degrees C (230 degrees F)
• Motor: Electric synchronous, spring return
• Positioning: 2-way, straight-through
