Copeland 045753 Solenoid Valve

Product Description

The Copeland 045753 solenoid valve is a two-way, normally closed diaphragm valve designed for various applications. It is suitable for liquid, suction, and hot gas services. This valve has extended ends for easy installation and allows brazing into the line without disassembly.

• Diaphragm valve for liquid, suction, and hot gas applications.
• Extended ends facilitate installation.
• Maximum working pressure of five hundred psi.

Product Highlights

This valve is often used in HVAC systems, providing reliable control for refrigerant flow.

Product Information

Standard Information

• Brand: Copeland
• MPN: 045753

Technical Specifications

• Vendor Part Number: 045753
• Connection Size: seven eighths inches
• Connection Type: ODF
• Maximum Differential Pressure: three hundred psi
• Maximum Operating Pressure: five hundred psi
• Overall Length: seven point thirteen inches
• Use Coil Model: AM, ASC2, DM
• Maximum Fluid Temperature: two hundred fifty degrees Fahrenheit
• MOPD: three hundred psi
• UL/CUL File Number: MP604
• Height: five point twenty-eight inches
• Capacity: fifteen point six tons
