Cooper Wiring Device AHCL1620C Color Coded Locking Connector 480 Volt 20 Amp NEMA L16-20

Product Description

The Cooper Wiring Device AHCL1620C is a four-wire, three-pole industrial-grade locking connector suitable for various applications. It operates at a voltage rating of four hundred eighty volts and carries a current rating of twenty amps. This connector accommodates cord sizes from zero point thirty-eight to one point sixteen inches and connects with conductors ranging from fourteen to eight AWG.

• Constructed with durable nylon to withstand harsh conditions
• Tin-plated brass contacts ensure optimal signal conductivity
• Meets standards including cULus, NOM, RoHS, and NAFTA

Product Highlights

The device features an EPDM gasket that keeps out dust and debris. It has back wire terminal clamps for easy wiring and individual wiring compartments for straightforward wire insertion. The clear cover over the wiring compartments allows visibility for easy inspection of terminations. The connector includes double dovetail cord clamps with reversible inserts, accommodating various cord diameters securely.

Product Information

Standard Information

• Brand: Cooper Wiring Device
• Country of Origin: China

Technical Specifications

• MPN: AHCL1620C
• Material: Nylon
• Voltage Rating: 480 Volt
• Amperage Rating: 20 Amp
• Number of Wires: 4
• Number of Poles: 3
• NEMA Configuration: NEMA L16-20
• Contact Material: Tin-Plated Bronze
• Conductor Size: 14-8 AWG
• Temperature Rating: -40 to 60 deg C
• Dimensions: 2.13 Inch Length x 2.3 Inch Width x 3.94 Inch Height
