Cooper Wiring 7623W-BOX Eaton Commercial Grade Decorator Switch 20A

Product Description

The Cooper Wiring 7623W-BOX is an Eaton commercial grade decorator switch. This three-way switch is rated for 20A and 120/277V, suitable for various applications including motor control, fans, LEDs, and lighting. It features a thermoplastic construction and an antimicrobial paddle for enhanced hygiene.

• Antimicrobial paddle
• Flush mounting method
• Suitable for commercial applications

Product Highlights

The Cooper Wiring 7623W-BOX decorator switch is ideal for commercial settings, offering a maintained closure type and compatibility with a range of load types.

Product Information

Standard Information

• Brand: COOPER WIRING
• Manufacturer Part Number: 7623W-BOX

Technical Specifications

• Product Name: Eaton commercial grade decorator switch
• Catalog Number: 7623W-BOX
• UPC: 032664647390
• Product Length/Depth: 1.29 in
• Product Height: 4.19 in
• Product Width: 1.18 in
• Compliances: RoHS Compliant
• Certifications: UL Listed cULus Listed
• Product Type: Commercial grade decorator switch
• Allowable wire size: #14-10 AWG
• Type: Switch decorator
• Amperage Rating: 20A
• Voltage rating: 120/277 V
• Number of poles: Three-way
• Phase: Single-phase
• Wiring method: Back and push
• Switch type: Three-way
• Mounting method: Flush
• Closure type: Maintained
• Load type: CFL Fan LED INC Motor Control ELV FLR HAL MLV
• Material: Thermoplastic
• Actuator: Antimicrobial paddle
• Amps: 20
• Poles: 1
• WIRING: BACK, SIDE
• WALL PLATE INCLUDED: NO
• FLAMMABILITY RATING: UL 94 V-2
• TEMPERATURE RATING: -20 TO 60 DEG C
• APPLICATION: COMMERCIAL
