Cooper Bussmann HPG Fuse Holder 30A

Product Description

The Cooper Bussmann HPG is a panel mount fuse holder suitable for Class J fuses. This unit is rated for up to thirty amperes and six hundred volts. It is designed with one-fourth inch quick connect/solder terminals which makes it easy to connect within various electrical setups.

• Panel mounting for secure installation
• Rated for a maximum current of 30A
• Equipped with quick connect/solder terminals for simple connections

Product Highlights

This fuse holder ensures safe circuit protection with a solid construction and straightforward installation process.

Product Information

Standard Information

• Product Name: Eaton Bussmann series HPG panel mount fuse holder
• Catalog Number: HPG

Technical Specifications

• UPC: 051712740456
• Product Length: 0.99 inches
• Product Height: 2.35 inches
• Product Width: 0.99 inches
• Voltage Rating: 600 V
• Class: Class J
• Connection: 1/4 inch quick connect/solder terminal
• Mounting Method: Panel
• Material: Metal
• Main Function: Fuse holder
• Rated Current: 30A
• Rated Voltage (AC): 600Vac
• Dimensions: 1.125 x 2.63 inches
• Thermal Resistance: UL 94-V0 (body); UL 94-HB (knob) flammability rating
• Manufacturer Product Status: Commercialized
