Cooper Bussmann ECNR15 Time-delay Fuse 15A 250V Class RK5

Product Description

The COOPER BUSSMANN ECNR15 is a time-delay, current-limiting, dual-element fuse rated for 15 amps at 250 volts AC and 125 volts DC. It carries a Class RK5 rating and delivers 200 kAIC interrupting capacity, making it suitable for circuits that require high fault-current protection. The dual-element design provides superior overload and cycling tolerance, holding through motor inrush and temporary overloads without nuisance opening while still responding quickly to short-circuit faults. Electricians and maintenance technicians install this fuse in fusible disconnect switches, panelboards, and motor-branch-circuit protection applications.

This fuse is used in residential, commercial, and light industrial electrical systems where Class RK5 time-delay protection is required. Its ferrule-end construction fits standard Class R fuseholders rated for 250-volt service. The 8-second time-delay at 500 percent of rated current makes it well suited for motor circuits, transformer primaries, and other loads with high inrush demands. It is a non-indicating fuse, meaning no visual blown indicator is present.

Key Features

• Time-delay operation: holds for 8 seconds at 500 percent of rated current to ride through motor inrush
• Dual-element design provides independent overload and short-circuit protection in a single fuse body
• 200 kAIC interrupting rating for use on high available fault-current systems
• Class RK5 rating fits standard Class R rejection-style fuseholders
• Ferrule end x ferrule end termination for secure seating in cylindrical fuseclips
• Non-indicating body — no blown indicator present

Compatibility

Designed as an OEM-style replacement for Class RK5 time-delay dual-element fuses in 250-volt fusible disconnect switches and branch-circuit fuseholders accepting ferrule-end fuses.

Installation Notes

Installation must be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the circuit using appropriate LOTO procedures before removing or inserting any fuse. Verify that the fuseholder is rated for Class R rejection to maintain the Class RK5 listing. Confirm that the replacement fuse amperage, voltage rating, and interrupting rating meet or exceed the circuit requirements before energizing.

Technical Specifications

• Amperage Rating: 15 amps
• Voltage Rating (AC): 250 volts
• Voltage Rating (DC): 125 volts
• Interrupting Rating: 200 kAIC
• Fuse Class: Class RK5
• Fuse Type: Time-delay, dual element, current-limiting
• Time-Delay Characteristic: 8 seconds at 500 percent rated current
• Terminal Style: Ferrule end x ferrule end
• Indicating: Non-indicating
• UPC: 782634507307

Standard Information

• Brand: COOPER BUSSMANN
• Manufacturer Part Number: ECNR15
